Marine Generator

Marine Generator thumbnail-1
Marine Generator photo-1
US$ 1,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Boat
Stroke:
4 Stroke
Contact Supplier Request Quote Chat Now
Weifang Yidaneng Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Boat
Stroke 4 Stroke
Cylinder Multi-cylinder
Cold Style Other, Water-cooled
Start Electric Start
Place of Origin Shandong, China
Brand Name Yidaneng
Model Number 495/4100/4102/4105/6105/6126
Certification CE CCS
Warranty One year or 1500 running hours, 1 Year or 1500 running hours

Specifications

marine generator
1) 20~250kw, 4/6cylinder, water cooled
2) CE/ISO9001
3)One year or 1500 running hours warranty

DIESEL MARINE ENGINE:

 marine generator

Weifang Yidaneng diesel engine can be widely used as the main power for generator set, fixed power, engineering machinery, agricultural machines and water pump set. All series engines are developed on the basis of original model by optimizing its fuel system, air intake and exhaust system, cooling system and transmitting system, to achieve high performance reliability and economical efficiency. The engines mainly have following features: lower oil consumption, higher reliability, bigger torque, easy starting & maintenance, and better adaptability.



The main technical parameters of HFR4105ZC1 diesel engine

Engine Model

HFR4105ZC1

Manufacturer

Weifang Huayuan Diesel Engine Manufacture Co., Ltd

Brand

HUAFA

Type

Four stroke, in line, water cooled

Rating power(kw)

56

Engine Speed(rpm)

1500

Bore*stroke(mm)

105*125

Number of cylinders

4

Air input mode

Turbocharged

Compression ratio

16:1

Fuel consumption

≤239g/kw.h

Oil consumption

≤1.63g/kw.h

Speed regulator

Mechanical

Starting method

Electric starting, 24V

Cooling method

Forced water cooled

Lubrication method

Pressure & splash lubricating

Exhaust gas temperature

≤600°C

Net weight

620kgs

Application

Marine genset



The main technical parameters of HFR6105IZLD diesel engine:

Engine Model

HFR6105IZLD

Manufacturer

Weifang Huayuan Diesel Engine Manufacture Co., Ltd

Brand

HUAFA

Type

Four stroke, in line, water cooled

Rating power(kw)

132

Engine Speed(rpm)

1500

Bore*stroke(mm)

105*135

Number of cylinders

6

Air input mode

Turbocharged & inter-cooled

Compression ratio

16:1

Fuel consumption

≤210g/kw.h

Oil consumption

≤1.63g/kw.h

Speed regulator

Mechanical

Starting method

Electric starting, 24V

Cooling method

Forced water cooled

Lubrication method

Pressure & splash lubricating

Exhaust gas temperature

≤550°C

Net weight

670kgs



OUR ADVANTAGE

Professional diesel engine manufacturer, not simply assembler or trader

Decades’ years of manufacturing and exporting experience

Adopt International quality standards, to meet high quality requirement

Good reputation for Reliable quality & Reasonable price

Strong technical support

Advanced production line with skilled workers



SALES PROMISE

Huayuanpower provides a full line of brand new and high quality products. Each and every unit is strictly factory tested before shipment.

Quality warranty is according to our standard conditions: 12 months from date of bill of lading or 1000 hours of running, whichever comes first.



USER'S NOTICE

a. Please use the engine oil ,diesel and cooling water under manual’s request and check the engine oil height before start up the diesel engine(between up and low reticle of dipstick).

b.Fach start up should be in 10 seconds and don’t start up more than 3 times at least should be more than 2 minutes,and thereis 3-5 minutes to idle speed after start up.Clutch can’t grind in separately.

c. If there are “winter”and “summer” two switches,you should match it with cooler,and when it is summer,the switch should tum to “summer”and vice versa.

d. Please discharge the water of water box,engine body and cooler after usage in winter.

f. Please read manual in details before usage.

 marine generator

*Pls note we can produce the goods as customer's demand.The price will be muc more cheaper if large quantity.

* This series generators are powered by our own brand engine, which is also know as weifang engines/weichai engines.

*Radiator 40°C max, fans are driven by belt, with safety guard

*12//24V DC start motor and storage battery

*Brushless, self-excited, IP22/23, insulation H alternator

*Absorber to reduce vibration

*Dry type air filter, fuel filter, oil filter

*Main line circuit breaker

*Control system: Key start control panel as standard, digital auto start or ATS system is optional

*8 hours operation base fuel tank

*High efficient muffler to reduce noise

*Ripple flex exhaust pipe, exhaust siphon and flange etc.

*Genset type: open type or soundproof/silent type, or trailer type

* Maintenance and operation manual, quality certificate, etc.

*Rigorous testing must be done before delivery, including 50% load, 75%load, 100%load, 110%

and all protection function(over speed stop, high water temperature, low oil pressure, battery

charging fail, emergency stop)

*Certificate: ISO9001:2000, CE, BV
