negative pressure filling machine1.Filling water juice and vinegar
2.Suitable for PET bottle
3.CE and ISO
4.Capacity:2500bp
negative pressure filling machine
The filler can accurately fill drink which does not contain gas, such as white spirit fruit wine, juice and fruit It can also fill other liquid such as vinegar, milk and pesticide. It has advantages of no broken bottle, no clepsydra, and convenient maintenance and others. It also has overload protection and LCD as the filler works in fully sealed condition and no pollution comes out. It meets the Foodstuff Sanitation Law.
Model : | FG-12 | FG-24 | FG-32 | |
Production Capacity : | 1500-2500 | 3000-6000 | 5000-8000 | |
Applicable bottle type(mm) | Glass Bottle Polyester Bottle | Inner dia, at inlet 15~18 (mm) | ||
Outer dia, at body 60~80 (mm) | ||||
Bottle height 200~320 (mm) | ||||
Pop-top Can | Outer dia 53~65 (mm) | |||
Height 90~133 (mm) | ||||
Power : | 0.75kw | 1.1kw | 1.5kw | |
Overall Dimensions : | 1000×800×2000(mm) | 1330×1260×2200(mm) | 1450×1700×2500(mm) | |
Weight : | 500kg | 800kg | 1000kg | |
Machine Detail Photo Show:
Company View:
