Specifications
Small Capactiy Glass Bottle Water / Juice / Beer Filling Machine
The Small Capactiy Glass Bottle Water / Juice / Beer Filling Machine has the function of closeing filling valves when there is broken bottle, and washing away broken bottle. The vent pipe has automatic foam-removing device
The crafty cap-unscrambling and capping design with overloading protection and the function is sufficient. It is controlled by PLC.
Model | DGX14-12-5 | DGX18-18-6 | DGX24-24-6 |
Production Capacity(bph)(5ooml) | 2000-3000 | 4000-5000 | 6000-8000 |
Filling Pressure(Mpa) | ≤0.4 | ||
Applicable Bottle Type | Bottle DiameterØ50- Ø 100mm;Height:150-320mm ;Volume:330-1500ml | ||
Applicable Cap Shape | Plastic Screw Cap | ||
Gas Source Pressure(Mpa) | 0.6 | ||
Gas Consumption(m3/min) | 0.2 | 0.3 | 0.4 |
Total Power(kw) | 4.6 | 5.03 | 6.4 |
Total Weight(kg) | 2500 | 4200 | 5800 |
Dimension(L×W×H)(mm) | 2350*1700*2150 | 2830*2030*2030 | 3220*2300*2600 |
Model | DGX32-32-8 | DGX40-40-10 | DGX60-50-15 |
Production Capacity(bph)(5ooml) | 9000-11000 | 12000-14000 | 16000-18000 |
Filling Pressure(Mpa) | ≤0.4 | ||
Applicable Bottle Type | Bottle DiameterØ50- Ø 100mm;Height:150-320mm ;Volume:330-1500ml | ||
Applicable Cap Shape | Plastic Screw Cap | ||
Gas Source Pressure(Mpa) | 0.6 | ||
Gas Consumption(m3/min) | 0.5 | 0.55 | 0.6 |
Total Power(kw) | 8.07 | 9.56 | 11.18 |
Total Weight(kg) | 7000 | 9000 | 12000 |
Dimension(L×W×H)(mm) | 3450*2510*2710 | 3800*2800*2710 | 4510*3400*2900 |
Machine Detail Photo Show:
Company View:
