Specifications
Temperature thermocouple0-1300Deg C measurement range
Type J,K,E,PT100,CU50 Optional
Replace Dynisco's similar item
Extrusion Thermocouple WR-200
Discription
WR-200 Series temperature thermocouple adopts excellent temperature sensing elements; consummate encapsulation technology and perfect assemble process to insure the quality and performance.
This temperature thermocouple has the advantage of fast thermal response time, strong thermal resistance capability, high pressure resistance, various temperature elements to choose, diversiform installation etc.
Application
It is used for the temperature measuring and control in the erumpent processing of Chemical fiber, Rubber plastic, Food process and etc.
Specification
Model |
WR-200 |
Temperature range |
0 to 1300°C |
Output |
4-20mA optional |
Power supply |
10 ~30VDC |
error |
0.1%FS, 0.3%FS, 0.5%FS |
Media compatibility |
316L stainless steel |
Pressure connection |
1/2-20UNF, M14*1.5 |
Protection tube |
Stainless steel 6mm and 8mm dia. |
Insert length |
6inch, 9inch |
Tip Length |
0mm , 5mm, 10mm, 15mm |
Sensing element |
J, PT100 temperature sensor |
Electrical connector |
2PIN or PIN special connector |
Dimension
Order Guide : with "* "are required , with "---"is optional
Price, Package and Service
1, T/T, Western Union, MoneyGram
2, Any questions from your are welcome and will be replied in 24 hours.
3, 7 days replacement and 12 months repair free of charge for quality problem.
4, All goods will be fully checked by our QC.
5, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder.
6. Package: The goods will be put into the packing box with instructions and certificate of quality first.
Our main products contains melt pressure transducers, melt pressure transmitters, Industrial pressure transmitter, melt pressure gauge, Homogenizer pressure gauges, automotive/air pressure sensors, Intelligent digital indicator, level transducer, temperature transducer, Rupture disk, and etc. more than 80 series and 500 models products.
