SMT ESD Antistatic PCB Magazine Rack

535 x 530 x563mm esd PCB rack magazine antistatic Cassette

antistatic cassette

esd pcb rack

535 x 530 x563mm

 SMT ESD Magazine Rack

  1) SMT magazine rack is designed for the manufacture, assembly, storage and transfer of PCB.
  2) Screw and gear adjustment.
  3) Common type (60℃) and heat-resistant type(120℃, 160~200℃) are available.
  4) Surface resistance: 10e4~10e6 Ohm
  5) Base: Conductive plastic or stainless metal

Description

A: Overall Size: 355*320*363mm. 30pcs of PCB Plates can be stored.
B: Overall Size: 355*320*263mm. 20pcs of PCB Plates can be stored.
Sizes of PCBs to be accommodated: 350*(50-250)mm
Side guide slot: depth 3.5mm, width 5mm, pitch 10mm
The top and bottom boards are made of metal.
Gear track allow easy operation.

Surface resistance: 104~106Ω
Overall Size: 355*315*580mm. 50pcs of PCB Plates can be stored.
Sizes of PCBs to be accommodated: 350*(80-250)mm
Side guide slot: depth 3.5mm, width 8mm, pitch 10mm
The top and bottom boards are made of plastic. Stationary type.
Adjustable through screws.

Surface resistance: 104~106Ω
Common type and heat-resistance type are available
Overall Size: 355*320*563mm. 50pcs of PCB Plates can be stored.
Sizes of PCBs to be accommodated: 350*(50-250)mm
Side guide slot: depth 3.5mm, width 5mm, pitch 10mm
The top and bottom boards are made of metal. Stationary type.
Adjustable through screws.(Allowed to be put in ageing chamber.

Surface resistance: 104~106Ω
Resistant to 120℃

Overall Size: 460*400*563mm. 50pcs of PCB Plates can be stored.
Sizes of PCBs to be accommodated: 460*(50-330)mm
Side guide slot: depth 3.5mm, width 5mm, pitch 10mm
The top and bottom boards are made of metal. Stationary type.
Adjustable through screws.(Allowed to be put in ageing chamber.

Surface resistance: 104~106Ω
Common type and heat-resistance type(120℃ ) are available.
Overall Size: 535*460*570mm. 50pcs of PCB Plates can be stored.
Sizes of PCBs to be accommodated: 535*(50-390)mm
Side guide slot: depth 3.5mm, width 5mm, pitch 10mm
The top and bottom boards are made of metal.
Gear track allow easy operation.
