Welded wire mesh panel factory
Company introduction:
Anping County Shunxing Hardware Wire Mesh Co.,Ltd. was established in 1992 and registered in 2007,Shunxing company is a leading manufacturer of high performance fencing products,the main products is following:temporary fencing,gates,gabion boxes,decorative wire mesh,barbed wire,welded wire mesh,wire mesh fence,and so on.
We have standard production lines and complete quality control system to ensure high quality products and to meet our customers needs.Each month we export not less than 35 full containers.More than 81% products are widely exported to Europe,South America,Australian and some Asia countries and our company has earned a very good reputation in China.
Getting more please scan the website .
Detailed introduction:
1.Specification of welded wire mesh panel factory:
1>Wire diameter: 3.0-6.0mm
2>PVC coating thickness:(pvc spraying)0.15-0.2mm;(pvc dipped coat)0.5-1mm.
3>Aperture size:50x100mm,50 x 150mm,50 x 200mm,55x200mm,75 x 150mm
4>Forms of corrosion resistance:electric galvanizied+pvc spraying /pvc dipped coated,hot-dip galvanizied
5>Color:RAL 6005 green or as customer's design
1)straighten&cut short the wire
2)welding
3)bending
4)galvanizing
5)parkerizing
6)powder/pvc coating
7)packing
4.Welded wire mesh panel factory colors:
Dark green,blue,white,red,yellow,black,gery,etc as your request.Dark Green is most popular for Exporting.
welded wire mes fence panel--Dark green color
welded wire mesh fence panel--Black color
5.Welded wire mesh panel factory property:
Smooth and trim mesh surface,solid and uniform structure and superior integral performance,it wob't loose even subject to local cutting or pressure.It has the characteristics of corrosion-resisting and oxidation-resisting.
6.Welded wire mesh panel factory Application:
For expressway,railway,garden fences,decorative fences,security fences,barbed wire fences,
chain link fence,expanded metal fences,etc.
Suitable for houses and properties,companies,gardens recreation areas,parks.All kinds of colors can be coated according to customers' special requirements.
7.Common specification of welded wire mesh panel factory:
Panel height |
Panel Length |
Wire Diameter |
Mesh Size |
Folds No. |
1.03m |
2.0m |
Galv.+PVC Painted |
50*200mm |
2 |
1.23m |
2 |
|||
1.5m |
3 |
|||
1.53m |
3 |
|||
1.7m |
3 |
|||
1.73m |
3 |
|||
1.8m |
4 |
|||
1.93m |
4 |
|||
2.0m |
4 |
|||
2.03m |
4 |
|||
2.4m |
4 |
8.Welded wire mesh panel factory packing:
(1)It has soft sponge at the bottom of the pallet to avoid the pallet destroyed the panel
(2)It has 4 metal corners to keep the pallet more strong.
(3)It has metal plate under the plastic bandage to avoid the bandage to pressure the fence panel.
(4)It has wood plate on the top of fence panel which can protect the fence panels avoid being crushed by other pallets.
9.Welded wire mesh panel factory loading in container:
Welded wire mesh fence Post introduction for your reference:
10.Welded wire mesh fence post process:
1)cut short the tube
2)hole frilling
3)galvanizing
4)sandblasting
5)powder/pvc coating
6)rivet nuts installing
7)cups installing & packing
11.Specification of welded wire mesh fence post:
Post Style |
Post Size |
Post Height |
Rectangle Post |
40*60*1.2mm |
1.63m 1.83m 2.1m 2.13m 2.2m 2.23m 2.4m 2.53m 2.6m 2.63m |
40*60*1.5mm | ||
40*60*2mm | ||
Square Post |
40*40*1.2mm |
|
40*40*1.5mm | ||
60*60*2mm | ||
60*60*2.5mm | ||
Peach post |
50*70mm |
|
70*100mm | ||
Round post |
38mm*1.2mm |
|
40*1.5mm | ||
42*1.5mm | ||
48*2mm |
12.Packing of welded wire mesh fence post:
Plastic bag+Buddle+Bandage+Metal Pallets
1.Our products are strictly follow ISO9001,SGS,CE and BV certificate.
2.Customer request is available!
3.Any question,please feel free to contact us.We will do our best to serve you!
1.Payment Terms:30%T/T as deposit,the balance against the copy of B/L.
2.Delivery Times:15-25 days after we received the deposit.
If you want to know more about our product,please feel free to contact us.Welcome you to visit our factory!
