ZD126 D.C. Traction Motor for railway locomotive
Application:
ZD126 D.C. Traction Motor is one type of the max power put in narrowgaged Diesel Locomotive. Main characters: wide rage of adjusting speed with constant power, good commutation and good generality. The frame is provided with welded steel plate and hugging bearing structure; Armature winding cross and lie flat,;Use Kapton insulation film on armature; Use NOMEX insulation paper to insulate to the earth; Bind unidirectional weft less gage on the front end of the slot, bind nomagnetic coated tin wire on the back end; brush hand is reaction type, brush hand spring is spiral. Motor use good insulation materials, rotor and stator use vacuum pressure dip coating . The motor is mainly used on narrow-gaged locomotives
Technical parameter:
Rated Power |
310KW |
Rated Voltage |
500V |
Rated Current |
680A |
Rated efficiency |
91.5% |
Rated Speed |
755r/min |
Max speed |
3100r/min |
Rated air flow |
80m3/min |
Max voltage |
1200V |
Max current |
1000A |
Cooling method |
Forced external |
Weight |
1640kg |
Other motor for rail:
