ONN-M9 Cold Storage Lighting

ONN-M9 Cold Storage Lighting photo-1
US$ 20 - 63 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
LED
Warranty(Years):
2
Input Voltage(V):
24&220
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source LED
Warranty(Years) 2
Input Voltage(V) 24&220
Lamp Power(W) 24
Lamp Luminous Flux(lm) 2400
Lamp Luminous Efficiency(lm/w) 100
Color Temperature(CCT) Other, Optional
Working Temperature(℃) -40, 50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
IP Rating IP68
Certification CCC, CE, FCC
Place of Origin Guangdong, China
Brand Name ONN
Model Number Other, M9

Specifications

ld storage lighting;
2.Water-proof light;
3.High protection;
4.Certification:CE,RoHS.


Product Description




Product Name:

ONN-M9 Explosion-proof Lighting


 Application:


 Machineinterior lighting,;Various cold storage interior lighting;food factory, pharmaceutical factory,aquaculture industry,mushroomindustry(applicable for all the places which is not easy to change place,have the needs of water-proof,explosion-proof,it is the revolutionary alternatives of traditional "three anti-light" and explosion-proof lights).

  explosion-proof light
Technical Parameter:



BrandONNSurface temperature<50°C
Light source0.1W/PCS Mountingfixed by T-shape strap and screws
Lifespan of light source50000hours Place of originShenzhen, China
View angle120°IP grade IP65
Central LUX100Lm/W





ModelPower(W)Rated currentVoltageCCT
ONN-M9-B16/12/18/24W400/550/800/900mA24V5500-6000K
ONN-M9-B26/12/18/24W400/550/800/900mA24V4000-4500K
ONN-M9-C16/12/18/24W50/80/100/130mA220V5500-6000K
ONN-M9-C26/12/18/24W50/80/100/130mA220V4000-4500K













Selling Points:



1. Double energy saving,suitable for -30 to -40 degree working temperature,is a great choise for cold storage;

2.Adopt  die casting structure, waterproof glue, waterproof silicone, toughened glass etc, the waterproof, heat dissipation and highly uniform appearance;

3. ONN-M9 series products adopt imported from Taiwan 3014 lights, the light source is small in size, low thermal resistance, good thermal performance, low droop is the best choice of lighting lamps and lanterns;

4. Has a strong structure of patent protection, no more than his wife parts, concise and easy, 360 degree adjustment, a lamp installation Angle and pin installed in two ways, let the installation follow one's inclinations;

5. Allowance for design, and import smoky three stone capacitance, sharply raising drive life, modular design, once the drive end life convenient change;

6.Can reach up to IP67,with IP65 certificate for years.

7.Hot sales products in our market.

8.Lenght can choose:300/400/600/800mm

9.Power :8/12/18/24w can choose

10.3 years warranty

11.24v/220v can choose,can meet different clients needs;

12. installation:fixed by T-shape strap and screws.





Product Advantages:



1.Resistant to low temperature of -40 ° ,no frosting, instantaneous starting,larte double energy saving ,longlife ,maintenance free man hour cost,especially suitalbe for ultra-low temperature cold storage environments.



2.LED Cost & Energy Savings Operate at least save at 70% efficiency;

General Associated Cost Savings:

  • Energy
  • Maintenance
  • Labor
  • Material
  • Operational Costs.
  • Contributions To The Environment




Product Size Drawing:





ONN-M9 Cold Storage Lighting
ONN-M9 Cold Storage Lighting
ONN-M9 Cold Storage Lighting
ONN-M9 Cold Storage Lighting
ONN-M9 Cold Storage Lighting
