Oxygen gauge regulator
(EDGE ESS4, OXYGEN REGULATOR)
Features:
Easy to use
The EDGE Series regulators have easy to read gauges with enhanced graphics,color-coded knobs for quick gas identification, and offer more natural and safer hand/body positioning for adjusting delivery pressure.
-
Durable and compact
The advanced design makes them some of the most compact industrial regulators available on the market. Construction materials have been carefully chosen for optimum durability, including a forged brass body, stainless steel bolts, and a regulator housing cap constructed of a zinc-aluminum alloy which has nearly twice the yield strength of brass. -
Designed for performance
Outperforming traditional designs, Victor Professional EDGE Series regulators offer a more consistent flow performance over a wide range of cylinder pressures. -
Unmatched for safety
The EDGE Series regulators meet or exceed industry standards, passing the most stringent compliance testing. All EDGE regulators feature SLAM™ (Shock Limitation and Absorption Mechanism) technology built into the adjusting knob, providing additional strength, safety and protection of the regulator internals. Passes all CGA E-4 compliance testing, Heated Oxygen Impact Test, and requirements of the UL 252 Standard for Compressed Gas Regulators.
The ESS4 Series – the heavy duty, high capacity, single stage design regulator series that set the standard for the complete line of EDGE regulators. Its outstanding flow performance provides better flow control across a full range of cylinder pressures, with exceptional sensitivity and precision in delivery pressure.
- Forged brass body
- Zinc-Aluminum housing cap
- High impact ABS gauge guard
- Stem type seat mechanism
- External self reseating relief valve in high pressure models
- Sintered inlet filter – nickel plated bronze
- Color-coded SLAM™ impact absorbing safety knob
- Meets or exceeds CGA E-4, UL 252 and ASTM G-175 Promoted Ignition Test
Applications:
Pressure regulators have the function to reduce the current cylindr pressure (inlet pressure) to the desired working pressure (outlet pressure) for which the consuming have been constructed.
Specification:
| Model | Gas | Max Input Pressure (KPa) |
Max Output Pressure (KPa) |
Gauge Pressure Range (KPa) | |
| Max Input | Max Output | ||||
| JGR-50A | OXYGEN | 20000 | 1000 | 28000 | 1400 |
| JGR-50B | ACETYLENE | 2000 | 100 | 2800 | 200 |
