MDF PVC edge banding machine,Manual straight and curved edge banding machine
MDF PVC edge banding machine,Manual straight and curved edge banding machine
Functions:Premilling--Gluing--End trimming--Rough trimming--Fine trimming-- Scrapping--Buffing
Description:
1.The machine is used for MDF, wooden board and shaving board.
2.It can complete the processes of feeding work piece, feeding coiled material, cutting, end trimming, fine trimming,scraping and 3.buffing. It can achieve the level as same as foreign machines and the price is favorable.
4.It is especially suitable for the factory producing board furniture.
Technical Parameters
Model:YZFB-A-1
Thickness of panel:10-60mm
Min width of panel:60mm
Min length of panel:160mm
Thickness of belt:0.3-3mm(PVC)
Max. belt size higher than panel:1.5mm
Panel feeding speed:0-26m/min(Adjustable)
Air pressure:0.7Mpa
End cutting motor:2x0.5KW 12000r/min 200HZ
Fine trimming motor:2x0.75KW 12000r/min 200HZ
Buffing motor:2x0.25KW 1400r/min 50HZ
Heating power of glue tank:2.6KW
Panel feeding motor:2.2KW
Glue spindle motor:0.75KW
Power of accessorial heater:0.12KW
Total power:8.67KW
Outline size:4000x1200x1500mm
Net weight: about 1400kg
Manual edge banding machine
Technical Parameters
Model:YZFB-M
Total Motor Power:3.5KW
Overall size:1100x800x1150mm
Feed speed:15~23m/min
Panel thickness :10~60mm
Edge banding tape thickness:0.45~2mm
Panel width:≥60mm
Working air pressure:0.8Mpa
Weight:280kg
Service before sale
1, 24 hours online .Your inquiry will be quick reply by email .
Also can go through all questions with you by any online chatting tools (Wechat ,Whatsapp,
Skype ,Viber ,QQ , TradeManager )
2,Professionally and patiently introduction,details pictures and working video to show machine
Service on sale :
1,Test every machine and inspect the machine seriously .
2,Send the machine picture which you order , then packing it with standard export wooden
box after you confirm the machine is ok .
3,Delivery:If ship by sea .after delivery to seaport .Will tell you the shipping time and arrival
time. Finally, send all original documents to you by Express For Free.
If delivery it by Express to your door(DHL, TNT,Fedex, etc) or by air to your airport, Or logistic
to the warehouse which you request . We will tell you the tracking number after delivery.
Service after sale
1, Free insurance for goods
2, 24 hours online to solve any problem . Supply you English manual book and technical
support,maintain and install video to help you solve the problem, or dispatch worker to your
factory.
Questions/Answer |
1,What is the voltage/phase for this machine ? |
|
220V 50Hz/single phase ,380V 50Hz/three phase , 110V 60Hz/single phase also can made as the clients’ need |
2,What is the Mode of transportation ? |
LCL and FCL by ship ,By Express (DHL,TNT, Fedex etc) ,By air |
3,How long can we get the goods? |
we usually delivery in 3-5 working days, we will inform you shipping time based on your seaport. |
4,How long is the guarantee? |
we promise guarantee as one year for non-human damage factor. |
5,How should I do if meet some trouble while using? |
|
we can supply English manual book and also take a video for showing how to resolve the problems or dispatch our worker to your factory. |
6,What about Payment term? |
|
T/T(Telegraphic Transfer ) --30% as prepayment by T/T, after seen the copy of the B/L sent by fax, the balance of 70% should be effected . Western Union ,L/C ,Trade Assurance,Etc. |
7,What’s your MOQ |
1 set |
8, How can i contact with you ? |
|
You can send inquiry to me . Aslo can contact with me by Cellphone/Wechat / Whatsapp /Viber:0086-15890162785 Skype :bella-yize,QQ : 3162296161 |
Zhengzhou Yize Machinery CO.,Ltd’s factory was built in 2008, its exporting company wasassessed gold supplier in 2015 by alibaba. It is specialized in the production of wood working machinery, We will supply 100% QC inspection before shipment and 100% guaranteed after sales service.
