Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer

Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer thumbnail-1
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer thumbnail-2
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer thumbnail-3
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer thumbnail-4
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer photo-1
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer photo-2
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer photo-3
Input 100a 150a 200a 250a 300a Output 1a or 5a Split Core Current Transformer photo-4
US$ 1 - 10 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Jiangyin Spark
Model Number:
SCT-T24
Contact Supplier Request Quote Chat Now
Jiangyin Spark Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Jiangyin Spark
Model Number SCT-T24
Usage Current
Phase Single
Coil Structure Toroidal
Coil Number Other, as per customer datasheet





Split core current transformers with 5A or 1A output/ input 100a 150a 200a 250a 300a output 1a or 5a split core current transformer



SCT-T24 with 24mm hole diameter measures AC current from 100 to 300 Amps

Description:

SCT-T24 series split-core current senses AC current from 100 to 300 Amps passing through the center conductor. Split core CTs are designed for fast and easy installation.The split core design permits non-contact current measurements through magnetic field induction without requiring that the primary wire be taken offline and disconnected for CT installation.This method permits a safer,easy and portable current measurement.


Specifications:
Maximum continuous primary current 300 A AC
Current Ratio: as per custoemr need
Output: 5A/1A at rated current
Accuracy: ± 1% from 5% to 120% of rated current
Insulation Voltage: 600VAC
Maximum Primary Voltage: 5000VAC(Insulated Conductor)
Phase angle: Less than 2 degrees at 50% of rated current
Frequency Range: 50 Hz to 400 Hz
Operating Temperature: -15Cto 60C.
CE recognized, and RoHS compliant
Output and leads can be customized

Applications:
Sub-Metering Accurate Measurement
Data Loggers to analyze Building & Machinery Performance
Digital Fault Recorders
Smart Grid Application Features
Load Center
Three Phase Balance Control
In-Factory Display In-Home Display
Inverters for Solar & Wind Turbine Systems
Power Measurement Device For PLC



input 100a 150a 200a 250a 300a output 1a or 5a split core current transformer



 input 100a 150a 200a 250a 300a output 1a or 5a split core current transformer
