Function Upgrade integrate Digital screw counter brushless power supply

Specifications

Integrate Digital screw counter brushless power supply
* Signal Input/Output function for PLC control screwdriver

 Digital integrate Function Upgrade screw counter brushless power supply

(WITH CE/UL CERTIFICATED)(6 PIN)  ~ Function Upgrade - V3.0







Model  No.	SP-BC40HL501T/C6
Input Voltage	AC 100-240V, 50/60HZ
Output Voltage	DC 40V/32V/24V
Output Walt	220W
Count	1- 99
Count Method	Count-up / Count-down
Work with Sensor	ON / OFF
GATE Sensor	ON (2 Sensor) / OFF (1 Sensor)
Slow-Start Time Adjustable	0.1- 9.9 seconds
Slow-Start Speed Adjustable	Lo: 100% L1-L9: Rated speed  35%-85%
Running Time Limit - LO	0.0- 9.9 seconds
Running Time Limit - HI	0.0- 9.9 seconds
Reminder Mode	On / OFF / FF / EF with LED and buzzer
Auto ZERO	ON / OFF
Screwdriver Control	HI / LO: Slow-Start
Dimensions	247x130x100mm
Weight	2.4 kgs



♦ POWER SUPPLY WITH CE CERTIFICATED



♦ Recommend: To be ordered with the screwdriver together



♦ Suitable Model: EA-BN630 ~ EA-BN650  (10~50kg/cm ,0.98~4.9 Nm)

                               EA-BAN960 ~ EA-BTN9180 (20.4~183.6kg/cm ,2~18 Nm)



♦  Signal Input/Output function for PLC control screwdriver:



External inputs: Forward/Reverse/Disable/Confirm/Sensor/Clear



External outputs: OK/NG/OK ALL







For More Electric Screwdrivers, Please Click HERE!













Features:







♦ Convenience design combine power supply and screw counter





♦ Compatible with PLC based process control system; accurate counting on screw fastening.







♦ Auto leaning function built-in could judge the best setting value.







Able to setting running speed & timing by Slow-Start function.







♦ Selection on auto-reset retrieval or manual reset retrieval.







♦ Enhances the auto-identified screw fastening time mode, allow user to aim at simulating the duration of specific screw fastening.







♦ Displaying the number of unfinished screw counts, user can add external sensor switch to prevent operation error.







♦ Buzzer alert while complete a fastening cycle. Internal signal for detecting screw count is also able to connect external devices.







♦ Capable with output and input signal; accurate calculation through the signal of sensor to prevent improper operation. Suitable for semi or full automatic production line.
