Special 3D CNC Router Machine With 12 Spindles Rotaries

Specifications

3d cnc router machine with 12 rotaries
Servo motor
NC Studio control system
2.2kw air-cooling spindle
with 4th rotary 1

3D CNC Router Machine With12 Spindles Rotaries

CC-MS3015K12

Detailed Features:

1. 4 axis cnc machine, with 8 Rotaries and 8 spindles, which can work at the same time or independently, and every one's max effective working area is 150mm(diameter) by 1000mm(length).



2. With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving .



3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.



4.Has the 4^throtary which is used for engraving cylinder workpiece.



5.Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.



6.Has the function of re-carving after break point and power failure.



7. Adopting advanced YASAKWA servo motor and NC studio control system .



Applicable materials

Wood, plastic, density board, wave board, PVC, acrylic, crystal, aluminum board, light marble and other nonmetal materials and light metal materials.



Applications:

a.Wood processing : processing of various furniture such as door ,window, cabinet,craft wood door ,screen and so on .

b.Advertising: billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel,literal-hole cut,lightbox mold,stamp,mould

c.Art craft: engraving characters of any languagess and graphics on gifts and souvenirs.

d.Decoration: acrylic, density board, organic glass, soft metals like aluminum, etc.



Technical Specifications



Description	Parameter	Optional parameter
4th rotary axis max diameter	150mm	125mm, 200mm
Machine dimension	3000mm*2000*2000mm
Resolution	0.01mm
Lathe structure	Seamless welded steel structure
X,Y structure	Rack and pinion transmission, Hiwin square guide rail
Z structure	Imported ball screw
Max. idling speed	35m/min
Spindle motor power	2.2 KW	1.5kw
Spindle rotate speed	0-24000r/min
Working voltage	AC380V/50Hz	220v
Working mode	Yasakawa servo motor
the control system	NC studio control system .
Cooling mode	Air-cooling	water cooling
Dust-collect function	Yes
Work-holding	By clamp



The main features for 3D Scanner:

1.Nonetouch scanner way, more stable ,wide application ,such as complex shape objects, soft materials or mould objects.

2.very fast speed .

3. German standard optical scan .

4.very clear to check every scan detials.

5.can scan flat panel, 3D objects, relief,round or cube objects.



The standard Accessories:

The working live-action:





The competitive advantage



1. High soft, famous brand electric cables.



2. Original Imported spare parts .



3. We will provide you several kinds software for free, with English and Multilingual versions.



4. Perfect after sale service.



5. Timely reply to your any question



6. professional instructions for the machine, software and parts' using.



7. Any workstage is strictly processed according to Euro CE Quality Standard and ISO Quality Standard .



8. Our company has powerful strength in metal Machining.





The workshop detai:

The CE and ISO certificate:
