CNC router double heads for wood door 1325
The model is CC-M1325AH2
Standard Feature
1.Two spindles can be working synchronously as well as separately. which improve working efficiency highly. Only one spindle can reach the working size 1500*3000mm.
2. Whole machine is welded with seamless steel structure and is processed by high temperature tempering treatment and vibrating stress relief (VSR) to relief residual stress. The stability is excellent, not easy to be deformed.
3. Adopt imported ballscrew and Taiwan Hiwin Square Rail, high precision and long life time.(Adopt rack and pinion transmission, fast working, high efficiency and low cost. )
3. Adopting advanced DSP system with USB interface, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
4. Be compatible with several CAD/DAM designing software, e.g. Type 3/Artcam/Castmate/Wentai etc.
5. Has the function of re-carving after break point and power failure
6. Perfect lubricating system makes maintenance much easier.
7. Advanced design of the machine make sure strong cutting and guarantee the engraving precision.
Applicable industries:
Advertisement: engraving and cutting various labels and number plate.
Art craft: engraving characters of any languages and graphics on gifts and souvenirs.
Applicabe materials:
Wood, aluminum board, plastic, density board, wave board, pvc, acrylic, crystal glass, light marble and other nonmetal materials and light metal metarials.
Processing effect:
Our cnc router is widely used for cutting, milling, drilling, engraving various shade vulture, relief,etc.
The samples:
Technical parameter
Description |
Parameter |
Optional |
|
X,Y,Z working area |
1300*2500*200mm |
1500*3000*200mm |
2000*3000*220mm |
Single work piece size |
650*1250mm |
750*1500mm |
1000*1500mm |
Table size |
1440*3040mm |
1640*3400mm |
2140*3400mm |
Resolution |
0.01mm |
0.01mm |
0.01mm |
Spindle motor power |
3.0KW/4.5kw |
3.0Kw/4.5Kw/6.0Kw |
3.0Kw/4.5Kw/6.0Kw |
Max Spindle rotate speed |
24000r/min |
18000r/min |
|
Working voltage |
AC380V/50Hz |
|
|
Working mode |
Stepper |
Stepper/Servo |
|
Cooling mode |
Water-cooling |
Air-cooling |
|
Work-holding |
By Suction-Water cooling Vacuum Pump |
By clamp |
|
Dust-collect function |
Optional |
||
Max. idling speed |
35m/min |
||
X,Y,Z structure |
Rack and pinion transmission, Taiwan Hiwin Square linear orbit |
||
The main spare parts:
The samples:
The key concerns for Customer
a.How to choice a better CNC Router ?
1. Choice a suitable working area
Small size such as 600*900mm is mainly used for duoble-color board and acrylic .
The large size of the machine such as:1200*1200,1300*2500,1500*300,2400*500,it is mainly used for wood and pvc,the large size machine is suitable for engraving and cutting for large materials.
2. Choice a suitable spindle motor.
Spindle motor is one for important components for cnc router,the performance of cnc router put an important role in cnc router.
b.When the machine can’t work well,What should I do?
1.Our engineer is online for 24-hours, they can check the problems and then give you a sulutions in two hours.
2.Our machine are with one’s year warranty, If any problems of machine parts under “normal use”,new machine parts will be sent to you sooner .
3.Please rest assured that operation CD and manual will be offered along with machine,making you can operate the machine easily.
The certificate:
The workshop detail:
The package:
The canton fair :
Dear Friends ,
To save your valuable time , please kindly add informations as follows with your inquiry :
1.what’s your product name? kind and size? Can you send a simple sample to me?
2.What’s your material’s kind, length, width and thickness?
3.what's the local voltage?
We will reply to you with all details in 8 hours .
scarlett gao
Skype : scarlett gao
The phone:008613562499855
