Plus Weight Bed Stone Cutting and Engraving Cnc Router Machine

Plus Weight Bed Stone Cutting and Engraving Cnc Router Machine thumbnail-1
Plus Weight Bed Stone Cutting and Engraving Cnc Router Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
chencan
Model Number:
CC-S1325
Contact Supplier Request Quote Chat Now
Shandong Chencan Machinery Incorporated Company
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name chencan
Model Number CC-S1325
Main Axle Rotational Speed 0-24000r/min
Feeding Height 220mm
Milling Cutter Diameter 3.175-12.7mm
Weight 2000kg
Certification CE,ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. CE and ISO certification;
2. best quality
3. competitive price
4. good service

Chencan Heavy Stone marble engraving and carving CNC Router Machine  with Promotional pricing



Features:

  • Ø Lathe bed is welded with seamless steel structure and is processed by high temperature tempering treatment
  • Ø 4.5 kw water-cooling spindle
  • Ø 5.5kw Fuling inverter
  • Ø Three axes adopt Taiwan Hiwin high precision square guide rail, X and Y axes adopt rack and pinion transmission, Zaxis adopts Germany-made ball screw,with high precision and longevity.
  • Ø Adopting advanced DSP system with USB interface, operated with the handle
  • Ø The machine has water tank and automatic water cooling system for cutters.
  • Ø Water proof and dust proof design protects the transmission parts from broken.
  • Ø Perfect lubricating system makes maintenance much easier
  • Ø Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
  • Ø Has the function of re-carving after break point and power failure.
  • Ø Emergency stop system to control machine from working.
  • Ø We provide a set of cutters, software, necessary tools and accessories for free

Machine parts:

Plus weight bed stone cutting and engraving cnc router Machine



 Technician parameter:

Model

CC-S1325

Lathe body

Seamless welded steel structure  structure

X Y Z effective working area

1300*2500*300mm

Motion Speed

35m/min

Spindle Rotate Speed

0-18000r/min, variable speed

Table size

1440*3140mm*300mm

Resolution

0.05 mm

Spindle power rate

4.5KW water-cooling Spindle

Inverter

DELTA/fuling

X,Y structure

Rack and pinion transmission,

HIWIN square guide rail

Z structure

Taiwan-made ball screw

Driver

Stepper

Small Electronic parts

Schneider

Working Voltage

AC380V/50Hz 3-phase/220V optional

Operating system

DSP control system

Software

Type 3, ArtCam, Wentai

Cooling mode

water-cooling

Command

G code,HPGL,U00,mmg,plt

Diameter of cutter

φ3.175-φ20

Package

Wooden case





Applicable Industries

. Marble/Stone working: engraving on various granite,bluestone,marble,gritstone,

ceramic tile,soapstone,etc.

.  Metal working: can engraving on various colorful metals like aluminum,brass,etc.

. Wood working: engraving and cutting on any kind of wood,plastic,PVC,and so on.



Certificate:

Plus weight bed stone cutting and engraving cnc router Machine



Factory

Plus weight bed stone cutting and engraving cnc router Machine

Contact:

Plus weight bed stone cutting and engraving cnc router Machine



Lira Zhou



Export manager

Viber/Whatsapp ID:0086-13583195229

Skype:c

TraneManager ID:cn220191925

Facebook/linkedin/Wechat ID:Lira Zhou.





Working video link for reference:



1 1325 standard size with a big rotary device link: http://youtu.be/0VQObJnFVvU

2 8 spindle with 8 rotaries machine link:     http://youtu.be/vnxdaskz3hU

3 4 axis three spindle machine link:        http://youtu.be/8z5E3ruoRLs

4 Carousel ATC machine working link:   http://youtu.be/FbJ1iHR-Uk4

5 Linear type ATC machine with rotary device working link:   http://youtu.be/CI5JkWwk-Ww

6 Stadard 1325 plasma machine link:      http://youtu.be/hVqR7dhjkiQ

7 Plasma machine with spindle rotary device working link:http://youtu.be/bwhyGW2jMbg

8 Multipefunction machine with driller and saw head link: http://youtu.be/l7kNnHQAmWY

9 2524 big Mould machine with big rotary device working link:     http://youtu.be/fgfiJAVyI0Q

10 3D scanner working video link:       http://youtu.be/rRxW3nT4C64
