CHENCAN Machinery CNC Milling Machine 5 Axis Using Syntec 5 Axis Controller

Name: CHENCAN Machinery CNC Milling Machine 5 Axis Using Syntec 5 Axis Controller
Brand: CHENCAN
SKU: 130414883
Availability: InStock

US$ 50,000 - 60,000 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Shandong Chencan Machinery Incorporated Company

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name CHENCAN

Model Number CC-BS1530BG

Voltage 220V/380V

Power(W) varied

Dimension(L*W*H) 1530

Weight 4000kg

Certification CE, ISO

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

CNC Milling Machine 5 Axis

Product Highlight
The biggest advantage of this machine is that the 360 degree rotary attachment and 180 degree rotation spindle can work synchronously, which means true 5 axis working and that's where Syntec 200MA-5 axis controller comes.
If you are interested in this model, please send us an inquiry, we will show you its working video.

Technical Parameters
X Y working area	1500*3000mm
Z working area	1000mm
Rotary attachment	D200mmL800mm (0-360 degree rotate) In X direction*
Rotation spindle	Italy HSD atc 9KW (-90 to +90 degree rotate)
Precision	0.01mm
Max idling speed	30m/min
Working mode	Yaskawa Servo motors
Operating system	Taiwan Syntec, 200MA-5
Cooling mode	Air-cooling
Fixing	By clamps
Ball screw	Taiwan C5 level high precision ball screw
Guide rail	Taiwan Hiwin , 35mm
Driver	Yaskawa
Inverter	Delta
Gear reducer	Japanese brand
Small Electronic parts	France Schneider
Spindle rotating speed	0-24000r/min
Tool changer	8 pieces, linear type tool magazine
Calibration	Tool sensor
Power supply	AC220V/50-60Hz or 380V/50-60HZ
Command	G code, HPGL, U00, mmg, plt
Table	T slots table covered with PVC
Diameter of cutter	3.175-18mm
*Standard sizes (XY axis)**	12002400mm 13002500mm 20003000mm 30004000mm, etc
Options	1. Absorption strips/blocks with Tongyou vacuum pump 2. Dust collector 3. 360 degree rotation spindle
Customized sizes and upgrades for the components are available on request.

Optional 360 degree rotation spindle

Application
Applicable materials	Wood, EPS (any kind of foam) and other non-metallic materials.
Applicable industries	1. Mold industry: wooden ship model, wooden model aviation and many other wooden model. 2. Foam industry: can carve and cut on any kind of foam with 2D and 3D dimension processing.
Processing effect	Engraving, cutting, milling, drilling, relief, shadow, enchasement and so on.
More Samples

Package&Factory

FAQ
1. I never use this kind of machine before, is it easy to learn?
User-friendly English manual and operation video will be sent together with the machine. If there is still any question, we can talk through phone or Skype. Moreover, you could come to our factory to learn how to use it before shipment. Our technician will give you professional guidance.
2. If the machine has problems, what can you do to help?
Free parts will send to you within warranty time, and there are 24/7 technique support by mail and phone. Our after-sales staff can come to your workshop if the problem still can not be fixed.
3. How could I know if this machine is suitable for me?
Before ordering, we will provided every details of the machine for your reference, or you could tell us your work piece, our technician will recommend the most suitable machine for you. Furthermore, we can make a sample in advance for you to check if your drawing is provided.

Service and Guarantee
1. Technical supports and suggestions before you order a machine according to your work piece. 2. Professional instruction for the operation of the machine. 3. One year warranty, we will provide the consumable parts at cost price after the warranty period. 4. Our technician will come to your workshop if the problems can not be fixed through Internet or phone communications. 5. 24-hour technical support by email or calling.
Part Replacement
Customers have to send the broken parts to us within one week to our factory address: West Mingjia Road, Qihe Economic Development Zone, Shandong Province. We will check and send you the new one within one week. 1. Customer has to bear the cost of returning the broken parts. 2. If the broken parts is not man-made damaged, we will afford the cost of the new parts and its freight cost.
