Specifications
Semi-Automatic Machine1.Imported hydraulic drive system
2.Correction positioning device
3.Board is fed by hand
Video Link: /en_video/show-112.aspx
FM-700 Semi-Automatic Book Case Making Machine, Case Maker, Book Case Maker
Semi-automatic machine for case making, lining and mounting, suitable for the production of binders, book covers, calendars and other paper over board items. Its user-friendly and compact design, together with the ease of operation and set up, makes this machine suitable for all production requirments.
The machine is composed of:
Sheet Feeder:
-Automatic lifting table.
-Pneumatically controlled feeding head lifts the sheet from the back.
Gluer:
-Top-surface gluing unit.
-Suitable for hot animal glue and for PVA glue.
-Vacuum transport-belt.
-It allows gluing all kinds of covering materials.
Boarder Feeder:
-Board is fed by hand.
-Has registerd guides for accurate board positioining.
Wrapper:
-It turns in the four sides of the wrapping material.
-Automatically tucks the corners with an innovative precision device.
-High power nip-roller pressing unit.
-Ensures high and constant quality unit.
Delivery Tray:
-It allows non-stop unloading.
Main Specification
| Model | FM-700 |
| Maximum Size | 450mm×720mm |
| Minimum Size | 130mm×210mm |
| Board Thickness | 1.0-3.0mm |
| Paper Weight | 100-200g |
| Maximum Speed | 10-20picecs/min |
| Power Supply | 10KW |
| Dimension(L×W×H) | 8500×2400×1500mm |
| Machine Weight | 3200kg |
