jinan hot sale 5 axis cnc router for Foam
- 10 Set / Sets per Month
- QINGDAO
- T/T
- engraving cnc router,1325 woodworking cnc router 1300*2500*200
- engraving and milling machine,1325 woodworking cnc router 1300*2500*200
- engraver router,1325 woodworking cnc router 1300*2500*200
- dsp control cnc machine,1325 woodworking cnc router 1300*2500*200
- cnc woodworking router machine,1325 woodworking cnc router 1300*2500*200
- cnc woodworking router,1325 woodworking cnc router 1300*2500*200
Product Details
Condition: | New | CNC or Not: | CNC | Place of Origin: | Shandong, China |
Brand Name: | Chenca | Model Number: | CC-SF2560B-5S | Voltage: | 380V |
Power(W): | 13KW | Dimension(L*W*H): | 9000MM*2200MM*2200MM | Weight: | 8000KGS |
Certification: | CE ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
jinan hot sale 5 axis cnc router for Foam
Main components of the machine
1The European CE standard production
2 Spindle motor: Italy HSD 6 KW ISO40 water cooling spindle
3 Drive system: Japan YASKAWA
4 Control system: Syntec system
5 Inverter: Taiwan Delta
6Three-axis drive type: X axis high-precision rack, Y, Z axis ball screw, Original nut
7 Rail: Taiwan HIWIN 35MM square rails, lubrication-free lifelong
8 Cable: drag chain specific Cable, anti-jamming, anti-static; with high flexibility, long-term use will not break
9 Limit switch: Japan OMRON
10 Electrical components: France Schneider and Germany Siemens
11 Beam: steel beam stiffeners
12 Table: vacuum suction
Features:
1. This machine adopts the European Syntec numerical control system, high powerful, high processing density, and high speed.
2. All components are imported from international top brand.
3. Z axis height can be increased to 1.5 meters, large surface processing, suitable for large and mediumsized threedimensional surface processing.
4. Intelligent processing crossborder protection, to prevent the mechanical impact due to excessive design documents processing.
5. Diversity control can separately control the processing speed, idling speed, cutting speed, greatly improving the quality of processed product and processing efficiency
Applicable industry and material:
1. The mold industry: casting, automotive, wind power, ships, boats, aerospace industry, rail transport
2. The instrument industry: threedimensional surface of large musical instruments, cutting and shaping
3. Applicable materials: polystyrene foam (EPS), and wood, timber and nonmetallic carbon hybrid materials
Parameters
No | parameter |
| parameter |
1 | working area | X | 2000mm |
Y | 3000mm | ||
Z | 1000mm | ||
C | ±213° | ||
A | ±120° | ||
2 | accuracy | processing accuracy | ±0.04mm |
repositioning accuracy | ±0.05mm | ||
3 | structure | table | cast steel |
|
| XYZ structure | XY rack, Z ball screw |
4 | speed | max speed | ≥40000mm/min |
working speed | ≥30000mm/min | ||
5 | spindle | power | HSD 6 kw ISO40 |
speed | 24000rpm | ||
6 | work mode |
| YASKAWA servo |
7 | work voltage |
| AC380/50Hz |
8 | command |
| G code,F/S |
9 | control system |
| Syntec |
10 | NET weight |
| 12000kg |
Parts
Sample
Certificates
Welcome to visit our company
thank you for your interest in our CNC routers, please contact me directly as following:
Robert wang
Sales manager
Skype:Robertwang417
Trademanager:cn220305274
Whatsapp/Viber:008615053485099
Wechat:15269122861
Tel:0531 88078568
Fax:0531 88078968
Mob:0086 15269122861
