DIN 41612 3 row 48 pin straight female type
- 20000 Piece / Pieces per Month
- shanghai
- T/T PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | KSM | Model Number: | KSM-9001-16481C |
Type: | DIN | Application: | PCB | Gender: | Female |
Product Description
DIN 41612 3 row 48 pin straight female type
Material | Parameter | ||
Insulator: | 30%Glass filled PBT | Current Rating: | 2AMP |
Contact: | Brass | Withstand Voltage: | 1000V AC/Minute |
| Insulation Resistance: | 1000MΩ Min. AT DC 500V | |
| Contact Resistance: | 30MΩ Max. AT DC 100mA | |
| Operating Temperature: | -45℃~+105℃ |
Shanghai Zhouri Electronics Co.,Ltd was established in 1993,it is a company specializing in producing and selling connectors, terminal blocks, flat wire ,electronic plastic fittings, and harness processing .In 2007 Company established the production base, from trade to production. After nearly twenty years efforts, the Company starts taking shape.
The production specifications of the Company have reached more than 12,000 kinds.
In 2008 Company is entitled Shanghai Enterprise of Integrity and successfully passed ISO9001:2008 quality management system certification. Some of production are UL,CE,CQC certified. It is a governing member and vice president of China Electronic Chamber of Commerce,of Shanghai Electronic Chamber of Commerce.
The own brands of Company include : KaisiMa , KangSima(KSM) and FeiErDing. Distribution and agency : DEGSON terminal blocks ,CKM connector .The products are widely applied to the communication, smart grid, power, security, industrial control, automotive, instruments and meters, home appliance and other areas.
The company follow the purpose of good faith and quality, and in return the customers for the maximum preferential price as concept.
2 . Delivery Method: by sea, by air, or express such as DHL/TNT/UPS etc…
3 . Delivery Time: normally 7-15days, could be negotiable when order is urgent.
