Chencan 4 axis 3d cnc router for wood carving
1. four axis machine, with 4 Rotaries and 4 spindles, which can work at the same time or independently, and every one's max effective working area is 300mm(diameter) by 1500mm(length).
2. With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving .
3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
4.Has the 4th rotary which is used for engraving cylinder workpiece.
5.Well compatibility: CAD/CAM designing software e.g. Type3/Artcam/ Castmate/Wentai etc.
6.Has the function of re-carving after break point and power failure
7. Adopting advanced YASAKWA servo motor and NC studio control system .
1 Spindle motor: Domestic 3.5KW air-cooled spindle
2 Motor system:Leadshine servo motor
3 Operating system: NC studio system
4 Inverter: Fuling
5 Rail: Taiwan HIWIN square rails, lubrication-free lifelong
6 Beam: steel beam stiffeners
7 Cable: drag chain specific Cable, antijamming, antistatic; with high flexibility, longterm use will not break
8 Limit switch: Japan OMRON
9 Electrical components: Schneider and Siemens
10 Table: overall welding tempered aging treatment, strong and does not distort
1.Wood processing : processing of various furniture such as door ,window, cabinet,craft wood door ,screen and so on .
2.Advertising: billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel,literalhole cut,light box mold,stamp,mould
3.Art craft: engraving characters of any languages and graphics on gifts and souvenirs.
4.Decoration: acrylic, density board, organic glass, soft metals like aluminum, etc.
Description |
Parameter |
4th rotary axis max diameter |
300mm |
Machine dimension |
1800mm*1450*1500mm |
Resolution |
0.01mm |
Lathe structure |
Seamless welded steel structure |
X,Y structure |
Rack and pinion transmission, Hiwin square guide rail |
Z structure |
Imported ball screw |
Max. idling speed |
35m/min |
Spindle motor power |
3.5KW |
Spindle rotate speed |
0-24000r/min |
Working voltage |
AC380V/50Hz |
Working mode |
Leadshine servo motor |
the control system |
NC studio control system |
Cooling mode |
water-cooling |
Head |
Four heads |
Rotary |
Four rotaries |
1 Equipment installation
after the Equipment reached the user, the user must read the manual first and carry out installation,
Any need or questions. We will give you best service
2 Train
When we send the machine .we also send a CD for our customer that show them how to operate the machine and how to use the software .
If you still don’t know how to use this machine or the software . we can send our engineer to your country or you can send your engineers to our company and we train them .
the user can by call or email us any problems at any time.
3 After-sales service
One year warranty for machine maintenance,
manual to show customer how to maintain this machine
Forever service for problem-solving .
One set per fumigation-free wooden case
