Digital megger insulation resistance tester China Manufacturer
♦ Microprocessor control
♦ Insulation resistance, leakage current dual parameter display
♦ Intelligent clear function
♦ Range with automatic and manual modes
♦ Strong anti-interference ability
♦ Qualified and unqualified sound and light alarm
♦ Measurement of insulation resistance and dielectric material of wire and cable
Field test,periodic inspection and destructive test
♦ Testing insulation resistance and leakage current of switch equipment, relay, motor, generator and cable
♦ Measurement of the insulation resistance of electronic components and devices
Model |
HPS2683 |
||
Feature | |||
Displayer |
HD LCD display |
||
Maximum Reading |
9999 |
||
Measurement Function | |||
Measurement Parameters |
IR and LC |
||
Test voltage |
10V-1000VDC(Arbitrarily set) |
||
Voltage accuracy |
±1% |
||
|
Measurement Speed(time/sec) |
6 |
||
Range Mode |
Auto,Manual |
||
Charging timer |
999.9s |
||
Correction |
Full range open correction |
||
Measurement range | |||
IR |
100kΩ~10TΩ(105Ω-1013Ω) 10V: 100kΩ~100GΩ(105Ω-1011Ω) 100V: 1MΩ~1TΩ(106Ω-1012Ω) 1000V: 10MΩ~10TΩ(107Ω-1013Ω) |
||
LC |
0.001μA~200.0μA |
||
General Specification | |||
Working Environment |
0°C -40°C ,≤90%RH |
||
Power Supply |
198V -242V(AC),47.5Hz -63Hz |
||
Power Consumption |
≤40 VA |
||
Standard accessories:
♦ AC power cord
♦ User's manual
♦ Testing report
♦ Warranty card and certificate
♦ HPS26004 Special test line for insulation resistance tester
♦ Communication cable
Optional accessories:
♦ Software CD (PC Data Acquisition Software)
♦ USB to RS232 universal serial line (1.8 meters)
Technical Service:
♦ We have professional engineers who design the test methods and test fixture for the product,debugged test equipment parameter to reach the optimal performance.
♦ We provide free technical training and offer free equipment maintenance technology.
♦ We can design special test programs and test fixture according to the customer.
