Features:
1 Low permeability
2 HDPE lining systems are secure because leachate does not penetrate them
3 Methane gas will not escape from the HDPE cover system
4 Rainwater will not infiltrate an HDPE cap
5 Chemical resistance
6 HDPE, resistant to a wide range of chemicals, is not threatened by typical solid or hazardous waste leachates
7 Suitable for sludge and secondary containment around chemical storage facilities
8 Ultraviolet resistance
9 HDPE's resistance to UV exposure is further enhanced by the addition of carbon black
10 Additionally, with the absence of plasticizers, volatilization is not a problem
Reflective factor
Geotec offers its HDPE geomembranes in white and black
11 A white surface helps mitigate liner temperature extremes and aids visual inspection
Items Technical Data | 0.50mm | 0.75mm | 1.0mm | 1.5mm | 2.0mm | 2.5mm |
Thickness Deviation % | ±6 | |||||
Material | HDPE | |||||
Density | 0.94g/cm3 | |||||
Tensile strength Mpa≥ | 14.5 | 14.8 | 15.3 | 16.0 | 16.5 | 17 |
Breaking Elongation ≥ | 465 | 472 | 490 | 505 | 512 | 523 |
Tear Resistance KN/m ≥ | 81 | 83 | 85 | 87 | 89 | 90 |
Water Permeability g.cm/(cm2.s.pa≤ | 1.0×10-13 | |||||
-70 Low Termperature Brittleness | Passed | |||||
Size Stability % | ±3 | |||||
Carbon Content % | ≥2 | |||||
WidthxRoll length(m) | (2-8)x50m | |||||
