5050 0.5W uv Led Diode 365nm 380nm 395nm 405nm

5050 0.5W uv Led Diode 365nm 380nm 395nm 405nm thumbnail-1
5050 0.5W uv Led Diode 365nm 380nm 395nm 405nm photo-1
US$ 1.5 - 1.8 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
WEJ
Model Number:
WEJT50APW-2ABP01-61E
Contact Supplier Request Quote Chat Now
Shenzhen Yongerjia Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name WEJ
Model Number WEJT50APW-2ABP01-61E
Type LED
Package Type Surface Mount
Max. Forward Voltage 3.6V
Max. Reverse Voltage 5V
Max. Forward Current 60mA
Max. Reverse Current 10uA

Specifications

uv led diode
1.Taiwan Epiled chip
2.Wavelength:365nm 380nm 395nm 405nm
3.Pb-free, RoHS compliant
4.silver plated copper lead

5050 0.5W uv led diode 365nm 380nm 395nm 405nm



Features of uv led diode:

*Low power consumption

*Long life-solid state reliability

*Available on tape and reel

*RoHS compliant

*Application of uv led diode:printing/ink curing; adhesive curing; security identification;money dector

*Viewing Angle:120 degree





Product Description







Specification of uv led 365nm black light:

Forward Current 30mA
Peak Forward Current 300mA
Reverse Voltage 5V
Power dissipation 200mW
Operation Temperature -25 to 85°C
Storage Temperature -40 to 100°C
Forward Voltage 2.8~3.6V
Wavelength 365~370nm
Luminous power 15~25mW
Chip Epiled(Taiwan)
Wire bond material 99.99% pure gold wire
 Silicon

Sumitomo(Japan)



Mechanical Dimensions of 5050 uv led diode:

5050 0.5W uv led diode 365nm 380nm 395nm 405nm





Note:

1.All dimensions are in millimeters (mm);

2.XX is +/-0.1mm, XXX is +/-0.05mm unless otherwise noted;

3.The device has a single mounting surface, the device must be mounted according to the specifications.



Reliability test of UV LED diode:

5050 0.5W uv led diode 365nm 380nm 395nm 405nm



Packaging Dimensions Specification

5050 0.5W uv led diode 365nm 380nm 395nm 405nm







WEJ Factory:

5050 0.5W uv led diode 365nm 380nm 395nm 405nm
