Products details:
|
Part No.
|
Emitted Color
|
Resin color
|
Viewing Angle(1) 2θ1/2 |
WEJ5E90C-RBGN-BC |
red |
water clear |
100 |
green |
Parameter |
Symbol
|
Condition
|
Value |
Unit |
|||
Min. |
Typ. |
Max. |
|||||
|
Forward voltage
|
Vf |
If=20mA |
Red |
1.8 |
2.0 |
2.4 |
v |
Green |
2.8 |
3.1 |
3.4 |
v |
|||
|
Luminous intensity
|
Iv |
If=20mA |
Red |
200 |
--- |
500 |
mcd |
Green |
700 |
--- |
1400 |
mcd |
|||
|
Dominant wavelength
|
λd |
If=20mA |
Red |
620 |
--- |
630 |
nm |
Green |
525 |
--- |
535 |
nm |
|||
|
Peak wavelength
|
λp |
If=20mA |
Red |
--- |
640 |
--- |
nm |
Green |
--- |
520 |
--- |
nm |
|||
|
Spectral Line half-width
|
Δλ |
If=20mA |
Red |
--- |
20 |
--- |
nm |
Green |
--- |
20 |
--- |
nm |
|||
Packaging details:
a sealed Anti-Static bag, several bags with a carton
Services:
1. 3 years warranty
2. 5 years technical service team
fessional sales team
4.Fast delivery
Shipping:
Our products are all shipped by air normally, time-sensitive,
shipped by DHL,FedEx,TNT,UPS and so on.
Samples in stock,we can send them in 2 days,
and orders normally is sent out by 5-7days,or according to the quantity.
