china cnc router DT1224
Applications:
The Dragon Tech CNC Router is a professional machine, used for sign, graphic fabrication,2D/3D machining (wood, acrylic, plastics, PVC, MDF etc.), stone fixture, display manufacturing, solid surface machining, Non-ferrous sheet metalwork (aluminium, brass, copper and zinc).
Options:
Working size: different working size matching your requirements
Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle
Inverter: Delta inverter,Fuling inverter
Control system: DSP, Weihong NK105, Mach 3
Rails: shaft rails or Hiwin linear rails for X/Y/Z
Can equipe rotating axis, liubricating system, mist cooling system, and so on.
No. |
| Description |
| DT1224 |
1 |
| X,Y,Z working size |
| 1220*2440*100mm |
2 |
| Working table |
| PVC and T-slot aluminum table |
3 |
| Lathe structure |
| Welding steel tube frame |
4 |
| Transmission system |
| Ball screw for X/Y/Z; shaft rails for X/Z and Hiwin linear rails for Y |
5 |
| Driving system |
| Stepper motor and drivers |
6 |
| Repositioning accuracy |
| ±0.02mm |
7 |
| Max. travelling speed |
| 6000mm/min |
8 |
| Max. working speed |
| 3000mm/min |
9 |
| Spindle and collet |
| 1.5kw Chinese self-coolant spindle, ER16 |
10 |
| Spindle speed |
| 0-24000RPM |
11 |
| Working voltage |
| 220V/1ph |
12 |
| Max. consume power |
| 2.5kw |
13 |
| Operating system |
| DSP system |
14 |
| Command code |
| G code(*uoo, *nc, *mmg, *plt) |
P.S.
All the parts of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on .
