Specifications
CNC Router DT2030H, router cnc 2030H8, CNC router for woodworking
CE Standard
1. 3kw HSD spindle
2. Hiwin linear rails
CNC Router DT2030H8, router cnc 2030H8, CNC router for woodworking
Applications:
1. Furniture, general woodworking manufacturing
2. Cabinet making
3. 3 dimensional (3D) machining(sign, plastics, wood, molds, etc.)
4.Sheet plastic fabrication
Options:
1. Spindle: HSD spindle with different power, chinese GS spindle
2. Panasonic or Yaskawa servo motors
3. Inverter: Delta and Fulling
4. Lubrication for X, Y,Z
5. Mist cooling system
6. Semi-auto tool changer system
7. Rotary
8. Control system: DSP or Ncstudio, Mach3
9. Vacuum table: vacuum holding table, T-slot vacuum table
10. Germany Becker vacuum pump, Chinese vacuum pump
11. Dust collector
Descriptions:
Item |
Description |
|
Parameter |
1 |
X, Y, Z Traveling Size |
|
2000x3000x200mm |
4 |
Lathe structure |
|
Welding Steel Structure |
5 |
X Y Structure |
|
Rack pinion, HIWIN linear Rails |
6 |
Z Structure |
|
Ball screw, HIWIN linear Rails |
7 |
Max. Speed |
|
32000mm/min |
8 |
Max. Working Speed |
|
20000mm/min |
9 |
Spindle |
|
6Kw Italian HSD Spindle, ER25 |
10 |
Spindle speed |
|
0-18000RPM |
11 |
Working mode |
|
Stepper |
12 |
Working voltage |
|
AC220V/AC380V/3Phase/ 50HZ/60Hz |
13 |
Operating system |
|
NCstudio |
14 |
Collet |
|
ER25 |
15 |
Software |
|
Type3 software, ucancam software |
16 |
Gross Weight |
|
1000KGS |
P.S.
All the pars of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on .
