router cnc ,3D double heads CNC Router,multi spindle wood carving machine DT1925D
Applications:
1. Furniture, general woodworking manufacturing
2. Cabinet making
3. 3 dimensional (3D) machining(sign, plastics, wood, molds, etc.)
4. Sheet plastic fabrication
Descriptions:
No. |
| Description |
| DT1925D |
1 |
| X,Y,Z working size |
| 1900*2500*200mm |
2 |
| Working table |
| PVC and T-slot aluminum table |
3 |
| Gantry |
| Steel gantry |
4 |
| Lathe structure |
| Welding steel tube frame |
5 |
| Transmission system |
| Rack pinion for X/Y, Ball screw for Z; HIWIN linear Rails for X/Y/Z |
6 |
| Driving system |
| Panasonic Servo systerm |
7 |
| Repositioning accuracy |
| ±0.03mm |
8 |
| Max. travelling speed |
| 50000mm/min |
9 |
| Max. working speed |
| 30000mm/min |
10 |
| Spindle and collet |
| 3.5 kw Chinese HQD spindle, ER25 |
11 |
| Spindle speed |
| 0-24000RPM |
12 |
| Spindle speed |
| 2pc |
13 |
| Working voltage |
| AC380V/3ph |
14 |
| Max. consume power |
| 13kw |
15 |
| Operating system |
| DSP |
16 |
| Command code |
| G code(*uoo, *nc, *mmg, *plt) |
Options:
Driving systerm:Panasonic/Yaskawa/Delta servo systerm
Spindle: HSD,Colombo, Chinese GS/GDZ/HQD
Inverter: Delta inverter, Fuling inverter
Cintrol system: DSP, Mach3, Ncstudio, Syntec
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on.
Youtube link:
http://youtu.be/XqXA4LFsSWg //EPS engraving
http://youtu.be/R5tdVQhK7XY //Acrylic engraving
http://youtu.be/gFFCp_tUApU //DT1212-400 working
http://youtu.be/vpio8Xq_BrQ //Glass engraving
http://youtu.be/7jcLZQuQN6E //Plasma cutting
http://youtu.be/5_cfe1K9QmE //rotating axes *8
http://youtu.be/z9PSrnx8vKA //Stone engraving
http://youtu.be/C_df6-F6Xvk //Stone working
http://youtu.be/OEUzbA0RDKE //Melamine board cutting
http://youtu.be/A2-AO_WknL0 //Carousel magazine working
http://youtu.be/teGDfj9iWXk //Rotating axis working
table:
Panasonic servo system:
spindle:
DSP control sytem:
other parts:
other machines:
samples:
