Specifications
router cnc surfboardDT0404M can be used in construction models,Artistic 3D design,metal engravingrouter cnc surfboard DT0404M
Applications:
Construction models, artistic 3D design, Brass and Aluminum cutting and engraving. Protoype engraving, PCB holder and making tags.
Options:
Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle
Inverter: Delta inverter,Fuling inverter
Control system: DSP, Weihong NK105, Mach 3
Rails: shaft rails or Hiwin linear rails for X/Y/Z
Can equipe rotating axis, liubricating system, mist cooling system, and so on.
No. | Description | DT0404M | ||
1 | X,Y,Z working size | 400*400*200mm | ||
2 | Working table | aluminum table | ||
3 | Lathe structure | Welding steel tube frame | ||
4 | Transmission system | Ball screw and Hiwin linear rails for X/Z; table moving system for Y | ||
5 | Driving system | Panasonic servo system | ||
6 | Repositioning accuracy | ±0.02mm | ||
7 | Max. travelling speed | 8000mm/min | ||
8 | Max. working speed | 3000mm/min | ||
9 | Spindle and collet | 1.5kw water cooling spindle, ER16 | ||
10 | Spindle speed | 0-24000RPM | ||
11 | Working voltage | 220V/1ph | ||
12 | Max. consume power | 5.5kw | ||
13 | Operating system | NcStudio | ||
14 | Command code | G code(*uoo, *nc, *mmg, *plt) |
P.S.
All the parts of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter (DELTA or FULING) and the table of the machine also can be customized and so on .
