Specifications
stone engraving cnc router DTS1325,cnc stone carving machine DTS1325,engraving machine stonePanasonic Servo system
HSD spindl
stone engraving cnc router DTS1325,cnc stone carving machine DTS1325,engraving machine stone
Applications:
DragonTech ATC Router is suitable for hard woodworking, cutting and engraving on rosewood for furniture, indoor decoration, MDF and so on, with high speed and high precision.
Descriptions:
No. |
Description |
DTS1325 |
1 |
X,Y,Z working size |
1300*2500*200mm |
2 |
Working table |
Vacuum and T-slot aluminum table |
3 |
Gantry |
Steel gantry |
4 |
Lathe structure |
Welding steel tube frame |
5 |
Transmission system |
Rack pinion for X/Y, Ball screw for Z; HIWIN linear Rails for X/Y/Z |
6 |
Working mode |
Panasonic Servo systerm |
7 |
Repositioning accuracy |
±0.03mm |
8 |
Max. travelling speed |
50000mm/min |
9 |
Max. working speed |
25000mm/min |
10 |
Spindle and collet |
9kw HSD spindle, ER25 |
11 |
Spindle speed |
0-24000RPM |
12 |
Working voltage |
AC380V/3ph |
13 |
Max. consume power |
13kw |
14 |
Operating system |
DSP |
15 |
Command code |
G code(*uoo, *nc, *mmg, *plt) |
Options:
Driving system: stepper system, Panasonic/Yaskawa/Delta servo system
Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle
Inverter: Delta, Fuling
Control system: DSP, Mach3, Ncstudio, Syntec
Vacuum pump: Germany Becker pump, Chinese pump
Can equip rotating axis, lubricating system, mist cooling system and so on.
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
Contacts:
Mob:86-183-0644-5018
Skype: ivy.dragontech
Youtube link:
http://youtu.be/XqXA4LFsSWg
http://youtu.be/R5tdVQhK7XY
http://youtu.be/gFFCp_tUApU
http://youtu.be/vpio8Xq_BrQ
http://youtu.be/7jcLZQuQN6E
http://youtu.be/5_cfe1K9QmE
http://youtu.be/z9PSrnx8vKA
http://youtu.be/C_df6-F6Xvk
http://youtu.be/OEUzbA0RDKE
http://youtu.be/A2-AO_WknL0
http://youtu.be/teGDfj9iWXk
Spindle:
Dleta inverter:
DSP:
Panasonic servo system:
