Help CenterCNC Router Dts1325 for Granite, Brick,Glass, Sandstone, Tile and Marble Stone Cnc Rouer
Related Products
-
Cnc Carving Machine DTS1530DUS$ 8,000 - 15,000MOQ: 1 Set -
Mdf Cutting Cnc Machine DTS1325US$ 6,000 - 12,000MOQ: 1 Set
-
Router Cnc SurfboardDTS1325US$ 6,000 - 12,000MOQ: 1 Set
-
Dts1530 CNC Carving Marble Granite Stone Machine/ 3D CNC Stone Cutting / Sculpture Machine 1500*3000*300mmNegotiableMOQ: 1 Set
-
Timber Cnc Cutting Machine DTS1530DUS$ 8,000 - 15,000MOQ: 1 Set
Stone CNC ROUTER, Marble CNC ROUTERS, CNC ROUTER for STONE, CNC ROUTER from China, CNC Engraving machine for Stone, DTS1325
The stone engraving machine is used for lettering, embossing, line engraving, eyeful engraving and other processing on monument ,natural stones, hard boards, wood, glass, ceramics, jade or other materials.
It is widely used in producing tombstones, embossing patterns, line engraving on ceramic tiles, producing handicraft articles, etc.
Youtube link: http://youtu.be/XqXA4LFsSWg //EPS engraving http://youtu.be/R5tdVQhK7XY //Acrylic engraving http://youtu.be/gFFCp_tUApU //DT1212-400 working http://youtu.be/vpio8Xq_BrQ //Glass engraving http://youtu.be/7jcLZQuQN6E //Plasma cutting http://youtu.be/5_cfe1K9QmE //rotating axes *8 http://youtu.be/z9PSrnx8vKA //Stone engraving http://youtu.be/C_df6-F6Xvk //Stone working http://youtu.be/OEUzbA0RDKE //Melamine board cutting http://youtu.be/A2-AO_WknL0 //Carousel magazine working http://youtu.be/teGDfj9iWXk //Rotating axis working
NO. |
Discription |
Parameter |
|
1 |
X,Y,Z Working Area |
1300x2500x300mm |
|
2 |
X Y Structure |
Rack pinion, HIWIN linear Rails |
|
3 |
Z Structure |
Ball screw, HIWIN linear Rails |
|
4 |
Max. Working Depth |
150mm |
|
5 |
Max.Working Speed |
5000mm/min |
|
6 |
Spindle |
HSD 4.5kw Spindle (option: water cooling spindle) |
|
7 |
Spindle Speed |
0-18000RPM |
|
8 |
Working Mode |
Stepper(option: Panasonic or Yaskawa servo) |
|
9 |
Working Voltage |
AC380V/50/60Hz |
|
10 |
Operating System |
DSP System |
|
11 |
Collet |
ER25 |
|
12 |
Software |
Type3 software, UCANCAM V9 |
P.S.
All the pars of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on .
