Addressable Ws2801 Smd5050 Led Strip

Addressable Ws2801 Smd5050 Led Strip thumbnail-1
Addressable Ws2801 Smd5050 Led Strip thumbnail-2
Addressable Ws2801 Smd5050 Led Strip thumbnail-3
Addressable Ws2801 Smd5050 Led Strip thumbnail-4
Addressable Ws2801 Smd5050 Led Strip photo-1
Addressable Ws2801 Smd5050 Led Strip photo-2
Addressable Ws2801 Smd5050 Led Strip photo-3
Addressable Ws2801 Smd5050 Led Strip photo-4
US$ 11 - 13 MOQ: 5 Meters
Key Specifications
Get Latest Price
LED Light Source:
epistar smd5050 led strip
Type:
Flex LED Strips
Input Voltage(V):
dc5v
Contact Supplier Request Quote Chat Now
Shenzhen Centuryled Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen yantian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source epistar smd5050 led strip
Type Flex LED Strips
Input Voltage(V) dc5v
Lamp Power 7.68w
Lamp Luminous Flux(lm) 450-500
Color Temperature(CCT) 40
Working Temperature(℃) -40, 60
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE
Emitting Color RGB
Place of Origin Guangdong, China
Brand Name SJ
Model Number SJ-10032-2801

Specifications

ws2801 smd5050 addressable led strip:
1.dc5v,7.68w
2. 32leds/m
3. CE&Rohs
4.2 years'warranty

addressable ws2801 smd5050 led strip





Applications:



1.lights, back lights, cabinet lights, edge light, architectural lights for corridor, canopy, archway, lights for path
and contour marking; etc.
2.They can be a good choice for lights for hotels, restaurants, night clubs, coffee / wine bars, shopping malls,
various shops, cinemas, beauty centers, office fronts, even lights for household kitchens or living rooms, etc.



 Project on Youtube:

/watch?v=jvcHy4gvkxM

/watch?v=m4LWRF7pFH8





Features for addressable led strip:





LED Type SMD 5050 LED
Color Full color
Different lights changing modes Flash, Strobe, Fade, and Smooth.etc
LED Quantity 32 leds/Meter
Size L500cm (5M) x W1.20cm
Package 5 Meters / Reel
View angle 120°
Working Input Voltage DC5V
IC number 32pcs WS2801 IC
Output power 7.68W / 1 Meter
Working Tempreture -20° to 60°
IC chip WS2801  256gray level
PCB Background white&black
Waterproof waterproof & non-waterproof available



Product images for addressable led strip:



addressable ws2801 smd5050 led stripaddressable ws2801 smd5050 led strip

addressable ws2801 smd5050 led stripaddressable ws2801 smd5050 led stripaddressable ws2801 smd5050 led strip



t-1000s sd card controller for addressable led strip:



addressable ws2801 smd5050 led strip



related projects for addressable led strip:



addressable ws2801 smd5050 led strip



 addressable ws2801 smd5050 led strip



Control System:

1. Offline control: SJ-T-1000s, SJ-8000C for off-line working, can control max 2048 Pixels, 8192 Pixels.

2. Online control: SJ-T-200K, 300K for on-line working, can control max 4096,8192 pixels.

3. Compatible with Arduino, DMX 512.



Connection:
1) Signal wire: DC+, DAT, GND
2) DC+ and GND connect to power supplier;DAT and GND connect to controller
3) Relative Controller: SPI controller support WS2801; when use DMX decorder, can connect to DMX system
4) Support online control



certificates:





addressable ws2801 smd5050 led stripaddressable ws2801 smd5050 led strip
