EPS foam cnc router carving machine foam cutting machine

Name: EPS foam cnc router carving machine foam cutting machine
Brand: DragonTech
Price: USD $1,000 - 45,000 / Set

FOB Price

USD $1,000 - $45,000 / Set

1 Set(Min.Order)

Supply Ability 60 Set / Sets per Month
Port QINGDAO PORT CHINA
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	CNC or Not:	CNC	Place of Origin:	Shandong, China
Brand Name:	DragonTech	Model Number:	DTE1825	Voltage:	380V/3Ph
Power(W):	19kw	Dimension(LWH):	18002500700mm	Weight:	7t
Certification:	CE	Warranty:	12months	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

PALLET

Product Description

EPS foam cnc router carving machine foam cuttingmachine

Application:

Styrofoam CNC Router can work on wood, EPS and non-metallic carbon material, making automotive foam mold, wooden ship model aviation, trains and other wooden mold, carving 3D musica instrument, bumper, bonnet interior trim mold and aviation etc.

Description:

No.	Description	DTE1825
1	X,Y,Z working size	18002500700mm
2	Working table	PVC and T-slot aluminum table with 2 area
3	Gantry	Steel gantry
4	Lathe structure	Welding steel tube frame with cement filling
5	Transmission system	Rack pinion for X/Y, Ball screw for Z; HIWIN linear Rails for X/Y/Z
6	Driving system	YASKAWA servo system(3kw for X/Y, 3kw with the brake for Z, 850w for the 4^th axis and rotating axis)
7	Repositioning accuracy	±0.03mm
8	Max. travelling speed	50000mm/min
9	Max. working speed	30000mm/min
10	Spindle and collet	6kw HSD spindle, ER32
11	Spindle speed	0-18000RPM
12	Rotating axis	Dia.: 400mm
13	4th swiveling axis in spindle	±90 degree
14	Working voltage	380V/3ph
15	Max. consume power	19kw
16	Operating system	Syntec
17	Command code	G code(uoo, nc, mmg, plt)

Options:

Driving systerm:Panasonic/Yaskawa/Delta servo systerm

Spindle: HSD,Colombo, Chinese GS/GDZ/HQD

Inverter: Delta inverter, Fuling inverter

P.S.

All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
