4 axis gem carving machine DT4A2040

Name: 4 axis gem carving machine DT4A2040
Brand: DragonTech
Availability: InStock

FOB Price

US$ 25,000 - 35,000 / Set

1 Set(Min. Order)

Port QINGDAO PORT CHINA
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Place of Origin	Shandong, China	Brand Name	DragonTech
Model Number	DT4A2040	Voltage	380V/3ph
Power(W)	21kw	Dimension(LWH)	20004000900mm
Weight	8000kg	Certification	CE
Warranty	12 months	After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

PALLET

Product Description

4 axis gem carving machine DT4A2040

Product Description

Parameter

No.	Description	DT4A2040
1	X,Y,Z wrorking size	20004000900mm*180 degree
2	Working table	PVC
3	4th swivelling axis in spindle	±90 degree
4	Transmission system	Helical rack pinion for X,Y, ball screw for Z; HIWIN linear rails for X,Y,Z
5	Control system	Syntec
6	Driving system	Yaskawa
7	Spindle	9kw HSD spindle
8	Spindle speed	0-24000RPM
9	Max. travelling speed	50000mm/min
10	Max. working speed	30000mm/min
11	Repositioning accuracy	±0.03mm
12	Command code	G code(uoo, nc, mmg, plt)

Applications:

Styrofoam CNC Router can work on wood, EPS and non-metallic carbon material, making automotive foam mold, wooden metal aviation, trains and other wooden mold,carving 3D musical instruments,bumper,bonnet interior trim mold and aviation etc.

Options:

Diving system:Panasonic/Yaskawa/Delta servo system

spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle

inverter: Delta inverter,Fuling inverter

P.S.

All the parts of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter (DELTA or FULING) and the table of the machine also can be customized and so on .

Packaging & Shipping

Company Profile

Beijing Vigers Co., Ltd.

Our company is a professional CNC Router manufacturer, which focuses on the design and production of high-quality precise carving machines.Our main products are DT series CNC Routers for woodworking, advertising, marble, metal and plasma. We also produce special machines according to customers' requirements. We supply the different options for machines, for example HSD, COLOMBO and GS spindles, DSP, MACH3 and SYNTEC control systems, BECKER and Chinese vacuum pumps, PANASONIC and YASKAWA servo systems, Rotaries, and so on.We have a professional sales team and engineer team with more than 10 years' experience. Therefore, we can supply good training and services to customers perfectly. High quality machines and good services have earned us a good reputation in world markets. We hope to establish long-term business relationships with all customers and enjoy the benefits together.
