3d cnc router/CNC cutting machine DTE2040/cnc router
Application:
Styrofoam CNC Router can work on wood, EPS and non-metallic carbon material, making automotive foam mold, wooden ship model aviation, trains and other wooden mold, carving 3D musica instrument, bumper, bonnet interior trim mold and aviation etc.
Description:
No. |
|
Description |
|
DTE2040 |
1 |
|
X,Y,Z working size |
|
2000*4000*900mm |
2 |
|
Working table |
|
PVC |
3 |
|
Gantry |
|
Steel gantry |
4 |
|
Lathe structure |
|
Welding steel tube frame with cement filling |
5 |
|
Transmission system |
|
Rack pinion for X/Y, Ball screw for Z; HIWIN linear Rails for X/Y/Z |
6 |
|
Driving system |
|
YASKAWA servo system(3kw for X/Y, 3kw with the brake for Z) |
7 |
|
Repositioning accuracy |
|
±0.03mm |
8 |
|
Max. travelling speed |
|
50000mm/min |
9 |
|
Max. working speed |
|
30000mm/min |
10 |
|
Spindle and collet |
|
6kw Italian HSD spindle, ER32 |
11 |
|
Spindle speed |
|
0-18000RPM |
12 |
|
Rotating axis |
|
Dia.: 400mm |
13 |
|
4th swiveling axis in spindle |
|
±90 degree |
14 |
|
Working voltage |
|
380V/3ph |
15 |
|
Max. consume power |
|
21kw |
16 |
|
Operating system |
|
Syntec |
17 |
|
Command code |
|
G code(*uoo, *nc, *mmg, *plt) |
Options:
Driving systerm:Panasonic/Yaskawa/Delta servo systerm
Spindle: HSD,Colombo, Chinese GS/GDZ/HQD
Inverter: Delta inverter, Fuling inverter
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
