High Quality! CNC Router 4 Axis, Styrofoam CNC Router,Foam Cutting CNC ROUTER DTFS2040
US$ 20,000 - 45,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO PORT CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC Cutting Machine DTE2040/cnc RouterUS$ 6,000 - 13,500MOQ: 1 Set -
High Quality! CNC ROUTER, CNC Router 4 Axis, Styrofoam CNC Router,Foam Cutting CNC ROUTER DTFS2040US$ 20,000 - 45,000MOQ: 1 Set
-
CNC Router 4 Axis, Styrofoam CNC Router,Foam Cutting CNC ROUTER DTFS2040US$ 20,000 - 45,000MOQ: 1 Set
-
EPS Machine For Carving Foam CNC Router DTFS2040US$ 23,000 - 38,500MOQ: 1 Set
-
Styrofoam Machining Center DTFS2040US$ 23,000 - 38,500MOQ: 1 Set
Condition
New
CNC or Not
CNC
Place of Origin
Shandong, China
Brand Name
DragonTech
Model Number
DTFS2040
Voltage
380v 3p
Power(W)
18KW
Dimension(L*W*H)
2000*4000*1000mm
Weight
2300KGS
Certification
CE
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
CNC ROUTER, CNC Router 4 Axis, Styrofoam CNC Router,Foam cutting CNC ROUTER DTFS2040
1. 6kw HSD spindle
2. YASKAWA servo system
3. SYNTEC control system
4. Taiwan HIWIN linear rails
5. Taiwan DELTA inverter
Application
Mould Industry: wood mould, Automobile mould
Suitable Material: Wood, Styrofoam (EPS),Non-Metallic Carbonation Materials, etc.
| Item | Description | Parameter |
| 1 | X, Y, Z working area | 2000*4000*1000mm |
| 2 | Table size | 2000*4000mm |
| 3 | Resolution | ±0.03/300mm |
| 4 | Repeatability | ±0.05mm |
| 5 | Lathe sructure | Cast steel frame |
| 6 | X structure | Rack pinion, HIWIN linear rails |
| 7 | Y structure | Rack pinion, HIWIN linear rails |
| 8 | Z structure | Ball screw, HIWIN linear rails |
| 9 | Max. consume power | 15kw |
| 10 | Max. rapid | 0-15000mm/min |
| 11 | Max. working speed | 0-10000mm/min |
| 12 | Spindle power motor | 6kw chinese water cooling spindle, BT40(ER32) |
| 13 | Spindle speed | 0-24000RPM |
| 14 | Working mode | Japan yaskawa servo system |
| 15 | Working voltage | 3 phase AC380V/50HZ/60Hz |
| 16 | Command code | G code(*uoo,*nc,*mmg, *plt) |
| 17 | Operating system | Windows taiwan syntec system |
| 18 | Interface | Internet or USB |
| 19 | System memory | 256M (or pendrive) |
| 20 | Collet | BT40(ER32) |
| 21 | X, Y working delicacy | <0.01mm |
| 22 | Software | Type3 software, copy artcam software |
| 23 | Running circumstance | Temperature: 0°C~45°C |
| relative humidity: 30%~75% | ||
| 24 | Net weight | 8300KG |
| 25 | Gross weight | 8500KG |
P.S.
All the pars of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on .
