cnc 3040 usb , Advertising CNC ROUTER,Sign-making CNC ROUTER, CNC ROUTER 0404
Applications:
The DragonTech desktop CNC Router is a proffessional machine, used for sign and graphic fabrication, 2D/3D maching(wood, acrylic, plastic, PVC, MDF etc.),store fixture, display manufacturing, solid surface maching, non-ferrous sheet metalwork(aluminum, brass, cooper & zinc)
Descriptions:
No. |
| Description |
| DT0404 |
1 |
| X,Y,Z working size |
| 400*400*140mm |
2 |
| Working table |
| T-slot aluminum table |
3 |
| Lathe structure |
| Aluminum |
4 |
| Transmission system |
| Ball screw for X/Y/Z; shaft rails for X/Y/Z |
5 |
| Driving system |
| Stepper motor and drivers |
6 |
| Repositioning accuracy |
| ±0.02mm |
7 |
| Max. travelling speed |
| 4000mm/min |
8 |
| Max. working speed |
| 2400mm/min |
9 |
| Spindle and collet |
| 130w Chinese air-coolant spindle, ER11 |
10 |
| Spindle speed |
| 0-10000RPM |
11 |
| Working voltage |
| AC220V/1ph |
12 |
| Max. consume power |
| 600w |
13 |
| Operating system |
| Mach3 system |
14 |
| Command code |
| G code(*uoo, *nc, *mmg, *plt) |
Options:
Working size: different working size matching your requirments
Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle
Inverter:Delta, Fuling
Control systerm:DSP, Weihong NK105, Mach3
Rails:shaft rails or hiwin linear for X/Y/Z
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
Youtube link:
http://youtu.be/XqXA4LFsSWg //EPS engraving
http://youtu.be/R5tdVQhK7XY //Acrylic engraving
http://youtu.be/gFFCp_tUApU //DT1212-400 working
http://youtu.be/vpio8Xq_BrQ //Glass engraving
http://youtu.be/7jcLZQuQN6E //Plasma cutting
http://youtu.be/5_cfe1K9QmE //rotating axes *8
http://youtu.be/z9PSrnx8vKA //Stone engraving
http://youtu.be/C_df6-F6Xvk //Stone working
http://youtu.be/OEUzbA0RDKE //Melamine board cutting
http://youtu.be/A2-AO_WknL0 //Carousel magazine working
http://youtu.be/teGDfj9iWXk //Rotating axis working
other parts:
other machines:
samples:
