New condition mini wood pellet cnc engraver 6090 , hobby CNC Router DT0609,mini cnc engraving machine DT 0609 with price
Parameters:
No. |
Description |
DT0609 |
1 |
X,Y,Z working size |
600*900*100mm |
2 |
Working table |
T-slot table |
3 |
Transmission system |
Ball screw for X Y Z |
4 |
Working mode |
Stepper motor and driver |
5 |
Repositioning accuracy |
±0.02mm |
6 |
Max. travelling speed |
6m/min |
7 |
Max. working speed |
3m/min |
8 |
Spindle and collet |
2.2kw Chinese water-coolant spindle, ER25 |
9 |
Spindle speed |
0-24000RPM |
10 |
Working voltage |
AC220V/1ph |
11 |
Operating system |
DSP |
12 |
Command code |
G code(*uoo, *nc, *mmg, *plt) |
Options:
Working size: different working size matching your requirments
Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle
Inverter:Delta, Fuling
Control systerm:DSP, Weihong NK105, Mach3
Rails:shaft rails or hiwin linear for X/Y/Z
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
Following are some samples made by this machine:
We have our own factory:
We pass CE Certification:
We have almost all kinds of machine: 3 axis, 4 axis and auto-feeding cnc routers. If you have your own demands, we also can make for you according to your request.
Contact information:
Skype:ivy.dragontech
Tel:86-183-0644-5018
QQ:1263208647
