2020 cnc router for sign logo advertising with moving table, hobby CNC Router DT0202,mini cnc engraving machine
Parameters:
| NO. | Description | DT0202 | DT0303 | DT0404 |
| 1 | X, Y, Z working size | 200*200*100mm | 300*300*100mm | 400*400*100mm |
| 2 | XYZ structure | Ball screw, shaft rails | ||
| 3 | Resolution | ± 0.02/300mm | ||
| 4 | Repeatability | ± 0.02mm | ||
| 5 | Max. speed | 0-6000mm/min | ||
| 6 | Max. working speed | 0-3000mm/min | ||
| 7 | Spindle | 800W water cooling spindle, ER11 (Option: 1.5kw, 2.2kw water cooling spindle) | ||
| 8 | Spindle speed | 0-18000RPM | ||
| 9 | Working mode | Stepper motor and driver | ||
| 10 | Working voltage | Single phase AC220V/50HZ/60Hz | ||
| 11 | Command code | G Code(*uoo,*nc,*mmg, *plt) | ||
| 12 | Operating System | NcStudio ( Option: DSP system / Mach3 system) | ||
| 13 | X, Y working delicacy | <0.01mm | ||
| 14 | Software | Artcam | ||
| 15 | Working table | Aluminum moving table with clamps | ||
| 16 | Packing size | 600X800X850mm | 700*900*850mm | 900*1000*850mm |
| 17 | Gross weight | 80KG | 90KG | 100KG |
Options:
Working size: different working size matching your requirments
Spindle:300W, 600W, 800W, 2.2KW water/air cooling spindles
Inverter: Delta, Fuling
Control systerm:DSP, Weihong NK105, Mach3
Rails:shaft rails or hiwin linear for X/Y/Z
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
Following are some samples made by this machine:
We have our own factory:
We pass CE Certification:
We have almost all kinds of machine: 3 axis, 4 axis and auto-feeding cnc routers. If you have your own demands, we also can make for you according to your request.
