Home > Products > CNC router > Low Price Atc, Cnc Wood Carving Machine, Cnc Engravig Machine for Woodworking DT2060ATC

Low Price Atc, Cnc Wood Carving Machine, Cnc Engravig Machine for Woodworking DT2060ATC

Name: Low Price Atc, Cnc Wood Carving Machine, Cnc Engravig Machine for Woodworking DT2060ATC
Brand: DragonTec
Availability: InStock

FOB Price

US$ 2,000 - 40,000 / Set

1 Set(Min. Order)

Port QINGDAO PORT CHINA
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Place of Origin	Shandong, China	Brand Name	DragonTec
Model Number	DT2060ATC	Voltage	AC380V/3Ph
Power(W)	13kw	Dimension(LWH)	20006000200mm
Weight	3.5t	Certification	CE
Warranty	1.5 Year	After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

Wooden pallet

Product Description

Specifications

low price atc, cnc wood carving machine, cnc engravig machine for woodworking DT2060ATC
9kw HSD spindle

low price atc , cnc wood carving machine, cnc engravig machine for woodworking DT2060ATC

Applications:

DragonTech ATC Router is suitable for hard woodworking, cutting and engraving on rosewood for furniture, indoor decoration, MDF and so on, with high speed and high precision.

Descriptions:

No.	Description	DT2060ATC
1	X,Y,Z working size	20006000200mm
2	Working table	Vacuum and T-slot aluminum table
3	Gantry	Steel gantry
4	Lathe structure	Welding steel tube frame
5	Transmission system	Rack pinion for X/Y, Ball screw for Z; HIWIN linear Rails for X/Y/Z
6	Working mode	Panasonic servo systerm
7	Repositioning accuracy	±0.03mm
8	Max. travelling speed	50000mm/min
9	Max. working speed	25000mm/min
10	Spindle and collet	9kw Italian HSD spindle, ER32
11	Spindle speed	0-24000RPM
12	Working voltage	AC380V/3ph
13	Max. consume power	13kw
14	Operating system	Syntec
15	Command code	G code(uoo, nc, mmg, plt)

Options:

Driving system: stepper system, Panasonic/Yaskawa/Delta servo system

Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle

Inverter: Delta, Fuling

Control system: DSP, Mach3, Ncstudio, Syntec

Vacuum pump: Germany Becker pump, Chinese pump

Can equip rotating axis, lubricating system, mist cooling system and so on.

P.S.

All the pars of machine can do some changes to meet your requirements, such as the motor (step motor or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on

Youtube link:
http://youtu.be/XqXA4LFsSWg //EPS engraving
http://youtu.be/R5tdVQhK7XY //Acrylic engraving
http://youtu.be/gFFCp_tUApU //DT1212-400 working
http://youtu.be/vpio8Xq_BrQ //Glass engraving
http://youtu.be/7jcLZQuQN6E //Plasma cutting
http://youtu.be/5_cfe1K9QmE //rotating axes *8
http://youtu.be/z9PSrnx8vKA //Stone engraving
http://youtu.be/C_df6-F6Xvk //Stone working
http://youtu.be/OEUzbA0RDKE //Melamine board cutting
http://youtu.be/A2-AO_WknL0 //Carousel magazine working
http://youtu.be/teGDfj9iWXk //Rotating axis working
