Auto-feeding CNC Router DT1325, Cnc Furniture Machine With Loading & Offloading System & Auto Labeling

Name: Auto-feeding CNC Router DT1325, Cnc Furniture Machine With Loading & Offloading System & Auto Labeling
Brand: Dragontech
Availability: InStock

FOB Price

US$ 1,000 - 100,000 / Piece

1 Piece(Min. Order)

Port qingdao
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Place of Origin	Shandong, China	Brand Name	Dragontech
Model Number	DT1325	Voltage	AC380V/3Ph
Dimension(LWH)	13002500200mm	Weight	1600kg
Certification	CE	Warranty	1year
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

Wooden case/plywood case

Product Description

auto-feeding CNC Router DT1325,

cnc furniture machine with loading & offloading system & auto labeling

Parameter:

No.	Description	DT1325
1	X,Y,Z working size	13002500200mm
2	Working table	T-slot vacuum table
3	Gantry	Steel gantry
4	Lathe structure	Welding steel tube frame(8mm)
5	Transmission system	Helical Rack pinion for X/Y, Ball screw for Z
6	Working mode	YASKAWA servo system
7	Repositioning accuracy	±0.03mm
8	Max. travelling speed	50m/min
9	Max. working speed	25m/min
10	Spindle and collet	6.0kw HQD air coolant spindle, ER25
11	Spindle speed	0-24000RPM
12	Working voltage	AC380V/3ph
13	Operating system	Syntec
14	Command code	G code(uoo, nc, mmg, plt)

P.S.

All the parts of machine can do some changes to meet your requirements, such as the motor (Panasonic or YASKAWA), control system(Syntec, DSP or Ncstudio), and the size of the t

able of the machine also can be customized and so on

Following are some samples made by this machine:

Youtube Links:

http://youtu.be/vK5L0N8tuHU
http://youtu.be/TyrxLsA5_YM

We have our own factory:

We pass CE Certification:

We have almost all kinds of machine: 3 axis, 4 axis and auto-feeding cnc routers. If you have your own demands, we also can make for you according to your request.

Contact information:

Skype:ivy.dragontech

Tel:86-183-0644-5018

QQ:1263208647

Company Profile

Beijing Vigers Co., Ltd.

Our company is a professional CNC Router manufacturer, which focuses on the design and production of high-quality precise carving machines.Our main products are DT series CNC Routers for woodworking, advertising, marble, metal and plasma. We also produce special machines according to customers' requirements. We supply the different options for machines, for example HSD, COLOMBO and GS spindles, DSP, MACH3 and SYNTEC control systems, BECKER and Chinese vacuum pumps, PANASONIC and YASKAWA servo systems, Rotaries, and so on.We have a professional sales team and engineer team with more than 10 years' experience. Therefore, we can supply good training and services to customers perfectly. High quality machines and good services have earned us a good reputation in world markets. We hope to establish long-term business relationships with all customers and enjoy the benefits together.
