Specifications
casing cementing head for well drilling1. Compact, easy to connect
2. High-strength materials
3. Manifold connections
specifications:
api casing cementing head
Technology parameter
Specifications, (in) |
5½" |
6 5/8" |
7" |
7 5/8" |
9 5/8" |
10¾" |
13 3/8" |
|
Overall Length, mm |
1460 |
1500 |
1500 |
1550 |
1750 |
1750 |
1780 |
|
Manifold |
2"Union |
|||||||
|
I.D. of Plug Container, mm |
Φ125 |
Φ150 |
Φ160 |
Φ175 |
Φ225 |
Φ250 |
Φ320 |
|
|
Length of Plug Container, mm |
400 |
450 |
450 |
450 |
550 |
550 |
600 |
|
|
Working Pressure, MPa |
35,50 |
35,50 |
35,50 |
35,50 |
35,50 |
35 |
35 |
|
why choose us
1. Description :
The bottom connection of the casing head shall be either API perfect circle thread casing box or API standard trapeziform casing threaded box,socket welded connection and slip type connection as well.
It can be provided with weld-group supporting baseplate.
2. Features:
♦ Quick-latch adapter is designed to offer easier,faster and safer makeup for cementing casing.
♦ Able to couple with two plugs simutaneously and makes the drilling fluid fill into casing in turn and quickly.This can simplify the cementing operation and prevent cement pollution.
♦ Positive lever indicates plug releasing.
♦ Balance pipe is developed.
3. Welcome to our factory!!!
4. Our product range:
♦ pumping unit/ tubing pump/ sucker rod/ X-mas tree/ casing head/ casing pipe/ tubing pipe/ drill pipe/ polished rod/ coupling
♦ production packer/ water flow regulator/ tubing anchor/ safety joint/ screen pipe/ sand screen
♦ float collar/ float shoe/ casing centraliser/ stop collar/ cementing head/ stage collar/ cement basket/ cementing plug
♦ air cannon/ diesel fuel tank/ water jacket heater/ multifunction pressure vessel/ air tank
♦ mud tank/ shale shaker/ vacuum degasser/ desilter/ desander/ gas-luiquid separater/ mud gun/ centrifuge/ sand pump/ slurry agitator/ shear pump/ cyclone mixing device
♦ container house/ color steel sandwich panel house
♦ belt feeder
