API Float Collar and Float Shoe for Casing

US$ 15 - 1,200 MOQ: 10 Sets

Key Specifications

Place of Origin:

Henan, China

Brand Name:

Model Number:

5-1/2"~20"

Puyang Zhongshi Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin and others

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name ZS

Model Number 5-1/2"~20"

Type Other, float collar and float shoe

Machine Type Drilling Equipment

Certification API

Material Carbon Steel

Processing Type Forging

Use Well Drilling

Specifications

float collar and float shoe:
1. True Manufacturer.
2. API and ISO Certified.
3. SINOPEC's grade 1 supplier.

API float collar and float shoe for casing

API springcasing float collar and float shoe:

Float collar and float shoe are necessary conventional accessories for down---structure of casing string.The features are as follow:

(1)Inside structure are aluminum alloy,easy for drilling;

(2)Can be connected with same type casing directly;

(3)Reliable backpressure

(4)Valve seat and valve body can effectively prevent cement from flowing back;

(5)Hardness of the materials for the body is equal to API N-80.

Specification(in)		O.D.(mm)	Total length(mm)	I.D.(mm)	Min.Dia.(mm)	Conn Type	Affordable strength of back-pressure(Mpa)
Float Collar	5	141.30	500	110	50	5 BCSG	35
	5 1/2	153.67	530	112	55	5 1/2BCSG	35
	7	194.46	586	162.5	77	7 BCSG	35
	9 5/8	270	720	225	77	9 5/8 BCSG	35
	13 3/8	365	720	319	77	133/8 BCSG	35
	20	533.4	720	475	77	20 BCSG	35
Float Shoe	5	140.30	495	110	50	5 BCSG	35
	5 1/2	153.67	514	122	55	5 1/2 BCSG	35
	7	194.46	533	162.5	77	7 BCSG	35
	9 5/8	269.88	550	225	77	9 5/8 BCSG	35
	13 3/8	339.7	550	319	77	133/8 BCSG	35
	20	534	652	475	77	20 BCSG	35
