Help CenterLog Multi Blade Saw Machine, Type MJ 8180X/8180XC
Related Products
-
DELI Log Multi Blade Saw Machine, Type MJ8120XNegotiableMOQ: 1 Set -
DELI Log Multi Blade Saw Machine, MJ 8200NegotiableMOQ: 1 Set
-
DELI Log Multi Blade Saw Machine, MJ 8350NegotiableMOQ: 1 Set
-
DELI Log Multi Blade Saw Machine, Type MJ E8100NegotiableMOQ: 1 Set
-
DELI Log Multi Blade Saw Machine, Type MJ E8080NegotiableMOQ: 1 Set
|
Type 8180/8180V
|
max width: 180mm | max thickness: 180mm |
| min width: 90mm | min thickness: 90mm | |
| min length: 500mm | Feed speed: intelligent control | |
| max length: continuous | weight: 1842KG | |
| size: 3460*1450*14700 mm | main motor: 18.5KW*2 | |
| blade: diameter 305mm | electrical equipment:Taiwan brand |
Superiorities of Series 8 log multiple-blade saw
8 series has four power to make the log infeed smoother
Horizontal 8 series products, the combination of advantages of three series, four series , is a new generation with high quality. It’s a integrated machine of sawing logs, or square materials. This series with high stability, safety, high efficiency, operation and maintenance, a more simple material high polished, free press plane, have been exported to many countries
Various advantages:
principal axis:
made of high-quality materials, chromium plated , dynamic balance processing, high stability, wear-resisting rust.
Cooling system:
we use the patent ZL200920173954.7 of axis core water spray technology to make dustproof environmental protection and saw protection, which can prolong the saw blades service life.
Feed:
Adopt PC intelligent control system to identify wood size automaticly to change the feeding speed to protect sawblade and electric motor.
Arc four row chain make the wood beplaced in the middle automaticly. The entire three powers feed synchronous, powerfully,and give full play to the machine performance.
Case:
mainframe box enhances the steady performance of the equipment greatly and improve the service life of the blades. Meanwhile the mainframe box have gone through aging treatment to make it durable and keeping shape.
Bearing:
selecting the international well-known brand, dust-free heating assembly, high flexible degree of principal axis, the service life is long.
Blades:
using high quality imported saw blades, heat-resistant, wear-resisting, do not out of shape
Whole advantage:
nvenient saw blades handling
2. free combination of opening piece or square.
Machining scope: suitable for any kind of wood processing.
Machining efficiency: 20-40 cube/day.
