TXS03-04B Binocular Drawtube and Biological Microscope Theory binocular microscope

TXS03-04B Binocular Drawtube and Biological Microscope Theory binocular microscope

Technical parameter:

Eyepiece(1):

   Usually,the microscope is only equipped with wide-field and plano-scope eyepiece WF10X. If you need, we will also provide you wide-field eyepieces as WF5X, WF6X, WF12.5X, WF15X,WF16X, WF20X, or Huygenian eyepieces as 5X, 6X, 10X, 12.5X,15X, 16X. The specifications of WF10X are showed as following:

Objective(4):

In this microscope, the standard outfit of the objective system is DIN  achromatic objectives which are

4X, 10X, 40X (spring loaded), 100X (spring loaded, oil immersion). The objective 100X is a immersion lens.

When the 100X objective is used, between its top and the cover glass, should drop some immersion oil and

be sure to make the air bubble out. If there is some air bubble in oil, you may rotate the nosepiece once

more, or add more oil again. After finish observing, the top of the objective(100X and 40X) and the cover

glass should be cleaned at once. Otherwise the remained dry oil will impair the imaging quality in the next

observing. According to your requirement, we can also provide you infinity system plane-scope achromatic

objectives, infinity system achromatic objectives, plane-scope achromatic objectives, and semi-plan

achromatic objectives.

The specifications of the DIN achromatic objective system are showed as following:

Specifications:

45mm DIN Achromatic Objective: 4X, 10X, 40X(S), 100X(S, Oil)

Wide Field Plane-Scope Eyepiece: WF10X, WF16X

Total Magnification: 40X-1600X

Articulated Free Binocular Head, Interpupillary Distance: 55-75mm; 30° Inclined,

360° Rotatable

Double Layers Mechanical Stage: 140X155mm, Moving Range X-Y: 70X50mm

Ø2-Ø30mm Iris Diaphragm And Ø32 Filter

ABBE Condenser: N.A. 1.25

Coaxial Coarse And Fine Focusing Adjustable Mechanism: 25mm, Precision: 0.002mm

Built-in Adjustable Brightness Halogen Lamp 6V/20W

Packings:

Net Weight/Set: 6.4kg;
Package: 1 Sets/Carton 38X34X50cm
Gross Weight/Carton: 11kg
