Help CenterSemi-automatic Big Bag Powder Filling Machine
Related Products
Specifications
It is suitable for filling the powder materials which is nueasy to flow.filling machine, filling from 20-5000g.
We can supply a complete set according to the users' requirments
Specifications
It is suitable for filling the powder materials which is nueasy to flow.
filling machine, filling from 20-5000g.
This machine is manual aid can auto-complete following work: weighing, filling, nipping-bags, sealing bags, and conveying. Due to it is designed according the GMP standard, it more fits the fluidic or low fluidity materials, such as milk powder, fodder, rice powder, white sugar, coffee powder, monosodium glutamate, solid beverage, dextrose, pharmaceuticals, and agriculture pesticide, granular additive, dyestuff, and so on.
Main features:
The whole structure of the machine made of stainless steel except the motor, cylinder, electrical accessories, pneumatic components, sewing machine. In particular the application of GMP, food sanitation certification, and adapt to the amyctic materials.
With the overshooting inhibition, amendment of drop and Tolerance alarm functions.
Using the new type of international popular scale packaging control systems, high-precision high-speed measuring of the dedicated instruments, strong functions, high reliability and fully meet the requirements of continuous production.
Time can be set automatically to control the PVC conveyor belt to convey (the structure made of stainless steel): neatness, clean, wash with water.
With calibration procedures (with poise and calibration of linking): It’s convenient to adjust at any time, and it’s very useful for the long time of no use of the weight draft.
Easy to remove the residual material: the screw can be directly inserted and draw out alone for washing.
In order to ensure the stable performance, all of the devices are international brands: pneumatic components are Korean AIRTAC, touch-screen man-machine interface, easy operation.
Metering Mode:Weighing (with the packing bag)
Packing Weight :5— 50KG
Feeding Mode: Double screw feeder (or vibrator feeder)
Filling Accuracy: ≤±0.2%
Sealing Machine:heat sealing machine+sweaming machine
Filling Rate:≤3Bags/min
Power Supply: 3P/380V(1P/220V according your requirement) 50—60Hz
Total Power: 3.9Kw. (without the power for the air supply)
Total Weight: 300Kg
Overall Dimensions: 4500×1600×2400MM
About SPM
Shanghai Pharmaceutical Machinery Co. Ltd. (SPM) is recognized as a major pharmacy equipment manufacturer and supplier. Our company is founded in Shanghai, China, with a base of 20 years
of prior experience in the pharmaceutical industry. This has allowed us to expand our business in a
well-planned manner. We now offer a comprehensive line of quality pharmaceutical machines at
competitive prices. In addition, we can undertake turnkey projects for conceptual design, process
design, water treatment solutions, cleanroom design, etc.
SPM Products
Our products fall into four categories, which are solid preparation machinery,iquid-injection processing
machinery, pharmaceutical packaging machinery, and laboratory instruments. Some of our primary products
are pulverizers, blenders, granulators, sterilizing machines, blister packing machines, encasing machines, air
compressors, and tablet testing instruments. Our solid preparation equipment and liquid processing equipmen,which are corrosion resistant, highly effective, safe, and easy to use, are utilized in countless applications.
For example, our rotary tablet press presses granular materials into tablets, our capsule filling machine is
suitable for filling powdered or granular materials into capsules, and our freeze drying machine is mainly
used for the cryodrying of blood products, vaccines, antibiotics, and biological products. For more product
applications, please see our product page to find a complete list of our pharmaceutical machinery.
Projects
Customer Service
Our excellent customer service also includes the installation of our machines. To ensure smooth
performance, we also provide a one year warranty, and a spare set of wearing parts to our customers.
If any difficulty occurs, we will supply free spare parts and even on-site service, upon request.
Please contact us to help you with your particular spare parts of pharmaceutical equipment.
Industries Served
At SPM, we focus on fabricating efficient and technically sound pharmaceutical machines that meet or exceed our customers' expectations. Our vast product selection caters to numerous industries, worldwide. Some of the areas we serve are
- Food Industry
- Pharmaceutical Industry
- Chemical Industry
- Electronic Industry
- Ceramic Industry
International Markets
Our experience with pharmaceutical machinery throughout the world has built us a reputation as a
trusted pharmacy-equipment supplier. Currently, our products are exported to many parts of the
world, including Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Iran, Japan, Denmark, Romani,
Bulgaria, Russia, South Africa, Nigeria, USA, Australia, Canada, Argentina, Chile, and more.
