JT6315,0~500V/0~30A/300W LED Electronic Load
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Model Number:
JT6315
Power:
Other, Electronic, 300W
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JT6315,0~500V/0~30A/300W Electronic Load,LED Electronic LoadNegotiableMOQ: 1 Piece -
JT6314,0~500V/0~15A/300W LED Electronic LoadNegotiableMOQ: 1 Piece
-
JT6314,0~500V/0~15A/300W Electronic Load,LED Electronic LoadNegotiableMOQ: 1 Piece
-
JT6313,0~150V/0~60A/300W LED Electronic LoadNegotiableMOQ: 1 Piece
-
JT6313,0~150V/0~60A/300W Electronic Load,LED Electronic LoadNegotiableMOQ: 1 Piece
Place of Origin
Fujian, China
Model Number
JT6315
Power
Other, Electronic, 300W
Usage
Strength Testing Machine
Features
- Over current/voltage/power/temperature,polarity reversed protection
- CC,CV,CP,CR,DYNA,List,Sweep & OCP test modes
- LED mode,Simulating real LED loading
- Show complete test report and support step test
- Support up to 16 loads SYNC
- Full range current rising time:10μs
Specifications
| Model | JT6315 | ||
| Input Rating | Power | 300W | |
| Voltage | 0~50V | 0~500V | |
| Current | 0~3A | 0~30A | |
| Min.operating voltage | 2.8V@30A | ||
| Full range current rising time | 10μS | ||
| CC Mode | Range | 0~3A | 0~30A |
| Resolution | 0.05mA | 0.5mA | |
| Accuracy | 0.03%+0.05%FS | ||
| CV Mode | Range | 0~50V | 0~500V |
| Resolution | 0.5mV | 5mV | |
| Accuracy | 0.03%+0.02%FS | ||
| CP Mode | Range | 300W | |
| Resolution | 16Bit | ||
| Accuracy | 0.1%+0.1%FS | ||
| CR Mode | Range | 0.09Ω~50KΩ | |
| Resolution | 16Bit | ||
| Accuracy | 0.1%+0.0001R | ||
| LED Mode | Bandwidth | >100KHz | |
| Rd Coefficient | 0.001~1 | ||
| Dynamic Operztion Mode | Range | 10μS~50S | |
| Resolution | 2μS | ||
| Accuracy | 1μS+20PPM | ||
| Slew rate | 0.6A/mS~3A/μS | ||
| Voltage Meas | Range | 0~50V | 0~500V |
| Resolution | 0.2mV | 2mV | |
| Accuracy | 0.015%+0.03%FS | ||
| Current Meas | Range | 0~3A | 0~30A |
| Resolution | 0.01mA | 0.1mA | |
| Accuracy | 0.015%+0.05%FS | ||
| Ripple Meas | Range | 0~500V | |
| Bandwidth | 15Hz~250kHz | ||
| Accuracy | 0.03%+30mV | ||
