AT5120,20 Channels DC Resistance Meter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
OEM
Model Number:
AT5120
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AT526,33.000k Ohm AC Low Ohm MeterNegotiableMOQ: 1 Piece -
AT516,20M Ohm Good for Resistance MeasurementNegotiableMOQ: 1 Piece
-
AT516,20M Ohm Low Resistance MeterNegotiableMOQ: 1 Piece
-
AT515,1G Ohm Precision DC Resistance MeterNegotiableMOQ: 1 Piece
-
AT5110,10 Channels DC Resistance TesterNegotiableMOQ: 1 Piece
Place of Origin
Fujian, China
Brand Name
OEM
Model Number
AT5120
Display Type
Digital Only
Measuring Range
1μΩ~30KΩ
Testing Voltage
198V AC - 240V AC/110V
Accuracy Class
0.05%
Operating Temperature
0~80°C
Dimensions
264(W)mm*107(H)mm*350(D)mm
AT5120,20 Channels DC Resistance Meter
Product Overview
AT5120 is a brand new design wide range and multi-channel resistance meter with high accuracy, which can scan and test 20 channels of resistance and can set a comparator for each channel. AT5120 adopts high performance ARM micro processor control. The true-color 3.5 inches LCD can display 20 channels of resistance simultaneously. Resistance range 1μΩ~30KΩ and max display result 30,000 digits. Its temperature compensation function can adapt different testing requirements. It can be applied to automation equipment. RS232C and Handler interface output 20 channels so as to improve the testing ability of production automation.
Function & Benefits
- 20 channels resistance scan measurement
- 3.5 inch True-color TFT-LCD display
- Can set resistance high/low limit independently
- Temperature compensation function
- Keyboard lock function
Specifications
| Channel | 20 channels(Scanning test) |
| Parameter | DC resistance |
| Accuracy | 0.05% |
| Measurement Range | 1μΩ~30KΩ |
| Signal Source | Max current:<1A |
| Range | Automatic, manual |
| Speed | Fast and low can be adjustable |
| Result Display | 20 channels show |
| Max Reading | 30,000 |
| Adjustment | Short circuit zero reset within full range |
| Comparator | Independently set 10 channels |
| Trigger | Internal and remote |
| Display | 3.5 inch TFT LCD display |
| Interface | RS-232C interface (SCPI instruction set),HANDLER interface(PLC interface) |
| Temperature | Accuracy: 0.2°C, temperature range: 0~80°C |
| Method | Four-terminal shield for each channel(including 2 detection element and 2 driving element) |
| Power Supply | Voltage: 198V AC - 240V AC Frequency: 50/60Hz Power: Max 15VA |
| Dimensions | 264(W)mm*107(H)mm*350(D)mm |
| Weight | 4kg |
Applications
- Multiple winding transformer DC resistance measurement
- Coil DC resistance measurement
- Motors Multiple winding resistance measurement
