Guangzhou Wishun Computer Co., Ltd.: Guangzhou, Guangdong, China; Main products: Intel XEON CPU for server

Home > Products > E3-1200V3 > Intel Xeon CPU E3-1225 v2 SR0PJ CM8063701160603

Intel Xeon CPU E3-1225 v2 SR0PJ CM8063701160603

Name: Intel Xeon CPU E3-1225 v2 SR0PJ CM8063701160603
Brand: Intel
Availability: InStock

FOB Price

US$ 205 - 206 / Piece

1 Piece(Min. Order)

Port HK
Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Application	Server
Processor Brand	Intel	Processor Type	Intel Xeon
L2 Cache	8MB	Socket Type	Other, LGA1155
Main Frequency	3200 MHz	Brand Name	Intel
Model Number	E3-1225 v2	Place of Origin	Costa Rica

Product Description

Intel Xeon E3-1225 v2 specifications

General information

Type

CPU / Microprocessor

Market segment

Server

Family

Intel Xeon E3-1200 v2

Model number ?

E3-1225 v2

CPU part numbers

CM8063701160603 is an OEM/tray microprocessor
BX80637E31225V2 is a boxed microprocessor

Frequency ?

3200 MHz

Turbo frequency

3600 MHz (1 or 2 cores)
3500 MHz (3 cores)
3400 MHz (4 cores)

Bus speed ?

5 GT/s DMI

Clock multiplier ?

Package

1155-land Flip-Chip Land Grid Array (FCLGA 1155)

Socket

Socket 1155 / H2 / LGA1155

Size

1.48" x 1.48" / 3.75cm x 3.75cm

Introduction date

May 14, 2012

End-of-Life date

Last order date for consumer processors is January 23, 2015
Last shipment date for consumer tray processors is January 8, 2016
Last shipment date for boxed processors is July 10, 2015

S-spec numbers

	ES/QS processors	Production processors
Part number	QBZQ	SR0PJ
BX80637E31225V2		+
CM8063701160603	+	+

Architecture / Microarchitecture

Microarchitecture

Ivy Bridge

Platform

Carlow

Processor core ?

Ivy Bridge-H2

Core steppings ?

E0 (QBZQ)
E1 (SR0PJ)

CPUID

306A9 (SR0PJ)

Manufacturing process

0.022 micron High-K metal gate process

Data width

64 bit

The number of cores

The number of threads

Floating Point Unit

Integrated

Level 1 cache size ?

4 x 32 KB instruction caches
4 x 32 KB data caches

Level 2 cache size ?

4 x 256 KB

Level 3 cache size

8 MB

Physical memory

32 GB

Multiprocessing

Uniprocessor

Features

MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
F16C / 16-bit Floating-Point conversion instructions
EM64T / Extended Memory 64 technology / Intel 64 ?
NX / XD / Execute disable bit ?
VT-x / Virtualization technology ?
VT-d / Virtualization for directed I/O
TBT 2.0 / Turbo Boost technology 2.0 ?
TXT / Trusted Execution technology

Low power features

Enhanced SpeedStep technology ?

Integrated peripherals / components

Integrated graphics

GPU Type: HD P4000
Base frequency (MHz): 650
Maximum frequency (MHz): 1250
The number of supported displays: 3

Memory controller

The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1333, DDR3-1600
Maximum memory bandwidth (GB/s): 25.6
ECC supported: Yes

Other peripherals

Direct Media Interface 2.0
PCI Express 3.0 interface

Electrical / Thermal parameters

Thermal Design Power ?

77 Watt

Notes on Intel Xeon E3-1225 v2

Also ships as an embedded microprocessor
The processor has the following security, data protection and/or software features: Intel vPro technology and Identity Protection technology.
The CPU is compatible with DirectX 11.0, OpenGL 4.0 and OpenCL 1.2 APIs.
The graphics unit has the following software features enabled: Intel Quick Sync Video, Clear Video HD technology and InTru 3D technology.
