Help CenterProgram Pattern Sewing Machine
Related Products
-
Handbag Zipper Window Sewing Machine/automatic PatternUS$ 1 - 3,500MOQ: 1 Set -
Computer Pattern Sewing Machine for Patch; Rubber Logo; PVCUS$ 1 - 3,000MOQ: 1 Set
-
Computer Pattern Sewing Machine for Mobile Phone & Tablet Leather CaseUS$ 1 - 3,500MOQ: 1 Set
-
Industrial Computer Pattern Sewing Machine Machine Type XC-2010R Direct-drive Servo MotorsUS$ 1 - 2,900MOQ: 1 Set
-
XC-2516R High Quality Industrial Computer Pattern Sewing Machine ManufacturerUS$ 1 - 3,200MOQ: 1 Set
6040 Sewing Range 600*400mm
5040 Sewing Range 500*400mm
5030 Sewing Range 500*300mm
4020 Sewing Range 400*200mm
3020 Sewing Range 300*200mm
2516 Sewing Range 250*160mm
2010 Sewing Range 200*100mm
Model |
XC-2010R pattern sewing machine |
Sewing range |
200*100mm |
|
Max speed ( rpm )( <3mm ) ) Max speed is variant according to sewing machine |
Recommend speed: 2500 Max speed: 2500 |
Mode of operation |
color LCD touch screen in Chinese/English |
Feeding |
Intermission/Continuous |
Stitch gap |
0.1-12.7mm ( Min gap 0.1mm ) |
Max stitch |
50000stitch/pattern |
Max pattern |
999 |
Scale |
X, Y 10-200% ( min 0.1%) |
Mirror |
X, Y and origin |
Rotation |
360 |
Needle |
Based on thickness, DP*17 #18 |
Shuttle |
Twice as large capacity full rotary hook |
Press foot |
Pneumatic |
Outer press foot move range |
32mm |
Inner press foot move range |
20mm |
Inner press foot wove range |
4-10m |
Main motor |
Direct drive 750W |
Power supply |
AC220-240V |
CBM |
1200*960*1170mm |
Weight |
150kg |
Features:
(1)English HD color LCD display panel, the screen can be display sewing patterns,also with voice broatcast function.
(2) fast, stable, a soft voice,small vibration, sewn stitch beautiful.
(3) pattern can scan on computer drawing then by USB transfer to machine,can also hand make pattern on panel.
1.Computer pattern sewing machine can help companies save manpower, reduce wastage , improve quality, increase productivity, improve the company's customer satisfaction, in order to achieve the objective of improve the company's core competitiveness.
2.100% the stitch won't be off because of ourpatent device.
3. Selecting high abrasion resistance spare parts to ensure the stability and longer lifetime for the machines.
4. Movable and reversal presser to act as “ robotic arm” for sewing faster and avoiding getting workers hurt.
5.With automatic parking, automatic thread trimmer, automatic pine line, auto-dial line, automatic presser foot and other functions, easy operation.Regardless of how complex patterns can be a one-time perfect sewing, anyone skilled to operate the machines in a very short period of time.
6.Application items: handbag, suitcase, computer bag, golf bag, shoes, clothing, jeans, sports product, cellphone covers, belts, magic tape, reusable bags, toys, pet products, zipper, leather products. etc. It does not only make the product much more beautiful, but also increase the production efficiency.
Samples show:
a.The packing will use standard wooden case to ensure item not damage.
b.The shipping will confirm once the order be confirmed.
pattern sewing machine
pattern sewing machine
We have good technical team,experienced staff,perfect management system,produce high quality products to you.
XINGCHI SEWING MACHINE CO.,LTD is reaseach and development,production and sales of industrial sewing machine exterprise. The products used in handbags,case,leather goods,shoes,garment,sofa,golf,car ottomans,tents,mat,sports goods,exported to southeast asia,europe,africa,all over the world.
Our company is by "To the quality strives for the survial,to the reputation strves for the development" as the management theoty,with the exact part hardware,consummate technology,the advanced equipment is a prere-quisite,high quality design talents is support,the after-sale service with first-class sincerity is the guarantee,enjoys a high reputation.
programable pattern sewing machine
pattern sewing machine
