High Speed Direct Drive Automatic Single Needle lockstitch sewing machine
Stitch samples:
Model | XC-3020R |
Sewing Scope | 300*200mm |
Max speed ( rpm )( <3mm ) ) Max speed is variant according to sewing machine | Recommend speed: 2500 Max speed: 2500 |
Speed scope ( rpm ) | 200-2300 |
Feeding | Intermission/Continuous |
Stitch gap | 0.1-12.7mm ( Min gap 0.1mm ) |
Max stitch | 8000stitch/pattern |
Max pattern | 999 |
Scale | X, Y 10-200% ( min 0.1%) |
Mirror | X, Y and origin |
Rotation | 360 |
Needle | Based on thickness, DP*17 #18 |
Shuttle | Waver |
Press foot | Pneumatic |
Outer press foot move range | 32mm |
Inner press foot move range | 20mm |
Inner press foot wove range | 4-10m |
Main motor | AC Servo |
Power supply | AC220-240V |
CBM | 1200*1060*1170mm |
Weight | 230kg |
1.Computer pattern sewing machine can help companies save manpower, reduce wastage , improve quality, increase productivity, improve the company's customer satisfaction, in order to achieve the objective of improve the company's core competitiveness.
2.100% the stitch won't be off because of ourpatent device.
3. Selecting high abrasion resistance spare parts to ensure the stability and longer lifetime for the machines.
4. Movable and reversal presser to act as “ robotic arm” for sewing faster and avoiding getting workers hurt.
5. With automatic parking, automatic thread trimmer, automatic pine line, auto-dial line, automatic presser foot and other functions, easy operation.Regardless of how complex patterns can be a one-time perfect sewing, anyone skilled to operate the machines in a very short period of time.
6.Application items: handbag, suitcase, computer bag, golf bag, shoes, clothing, jeans, sports product, cellphone covers, belts, magic tape, reusable bags, toys, pet products, zipper, leather products. etc. It does not only make the product much more beautiful, but also increase the production efficiency.
a.The packing will use standard wooden case to ensure item not damage.
b.The shipping will confirm once the order be confirmed.
We have good technical team,experienced staff,perfect management system,produce high quality products to you.
XINGCHI SEWING MACHINE CO.,LTD is reaseach and development,production and sales of industrial sewing machine exterprise. The products used in handbags,case,leather goods,shoes,garment,sofa,golf,car ottomans,tents,mat,sports goods,exported to southeast asia,europe,africa,all over the world.
Our company is by "To the quality strives for the survial,to the reputation strves for the development" as the management theoty,with the exact part hardware,consummate technology,the advanced equipment is a prere-quisite,high quality design talents is support,the after-sale service with first-class sincerity is the guarantee,enjoys a high reputation.
Sample room:
Parts room:
Work shop:
INDIA GTE FAIR:
SHANGHAI CISMA FAIR:
